Figure 6-59. Procedure for Measuring Input Signal High-/Low-Level Width
Software Operation Hardware Status
TAU
default
setting
Power-off status
(Clock supply is stopped and writing to SFR of the TAU
is disabled.)
Sets the TAU0EN bit of peripheral enable register 0
(PER0) to 1 (when the TAU0EN bit is 0, read/write
operation is disabled).
Power-on status. Each channel stops operating.
(Clock supply is started and writing to SFR of the TAU
is enabled.)
Sets timer clock select register 0 (TPS0).
Determines operating clock (CK00 and CK01) for each
channel.
Channel
default
setting
Sets noise filter enable register 1 (NFEN1).
Sets timer mode register 0n (TMR0n) (determines
operation mode for each channel and selects the
detection edge).
Clears the target bit of timer output mode register 0
(TOM0) to 0 (master channel output mode).
Clears the target bit of the TOL0 register to 0.
Clears the target bit of the timer output enable register
(TOE0n) to 0.
Channel stops operating.
Operation
start
Sets the target bit of TS0 register to 1.
The target bit of TS0 register automatically returns to 0
because it is a trigger bit.
The target bit of TE0 register is set to 1, and the TI0n pin
start edge detection wait status is set.
Detects the TI0n pin input count start valid edge.
Clears timer count register 0n (TCR0n) to 0000H and
starts counting up.
During
operation
The TDR0n register can always be read (for the access
procedure to the TDR0nH and TDR0nL registers, see
6.2.2 Timer data register 0n (TDR0n)).
The TCR0n register can always be read (for the access
procedure to the TCR0nH and TCR0nL registers, see
6.2.1 Timer counter register 0n (TCR0n)).
The TSR0n register can always be read.
The set values in the target bits of the TO0, TOE0,
TOM0n, and TOL0n registers cannot be changed.
When the TI0n pin start edge is detected, the counter
(TCR0n) counts up from 0000H. If a capture edge of the
TI0n pin is detected, the count value is transferred to timer
data register 0n (TDR0n) and INTTM0n is generated.
If an overflow occurs at this time, the OVF bit of timer
status register 0n (TSR0n) is set; if an overflow does not
occur, the OVF bit is cleared. The TCR0n register stops
the count operation until the next TI0n pin start edge is
detected.
After that, the above operation is repeated.
Operation
stop
Sets the target bit of TT0 register to 1.
The target bit of TT0 register automatically returns to 0
because it is a trigger bit.
The target bit of TE0 register is cleared to 0, and count
operation stops.
The TCR0n register holds count value and stops.
The OVF bit of the TSR0n register is also held.
TAU
stop
Clears the TAU0EN bit of the PER0 register to 0.
Power-off status
(Clock supply is stopped and SFR of the TAU is
initialized.)
Remark n: Channel number
n = 0, 1 (for 10-pin products); n = 0 to 3 (for 16-pin products)
