RL78/G10 CHAPTER 6 TIMER ARRAY UNIT

R01UH0384EJ0311 Rev. 3.11 194

Dec 22, 2016

Figure 6-67. Example of Set Contents of Registers for One-Shot Pulse Output (Slave Channel) (2/2)

(e) Timer output mode register 0 (TOM0)

Bit p

TOM0

TOM0p

1: Sets the slave channel output mode.

Remark n: Master channel number (n = 0, 2)

p: Slave channel number (n < p ≤ 3)
