RL78/G10 CHAPTER 12 SERIAL ARRAY UNIT
R01UH0384EJ0311 Rev. 3.11 307
Dec 22, 2016
(1) Register setting
Figure 12-22. Example of Contents of Registers for Master Transmission of 3-Wire Serial I/O (CSI00, CSI01
Note
)
(1/2)
(a) Serial mode register 0n (SMR0nH, SMR0nL)
Symbol: SMR0nH Symbol: SMR0nL
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
CKS0n
0/1
CCS0n
0 0 0 0 0 0
STS0n
0 0
SIS0n0
0 1 0 0 0
MD0n1
0
MD0n0
0/1
Operation clock (f
MCK) of channel n
0: Prescaler output clock CK00 set by the SPS0 register
1: Prescaler output clock CK01 set by the SPS0 register
Interrupt source of channel n
0: Transfer end interrupt
1: Buffer empty interrupt
(b) Serial communication operation setting register 0n (SCR0nH, SCR0nL)
Symbol: SCR0nH Symbol: SCR0nL
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
TXE0n
1
RXE0n
0
DAP0n
0/1
CKP0n
0/1 0
EOC0n
0
PTC0n1
0
PTC0n0
0
DIR0n
0/1 0
SLC0n1
0
SLC0n0
0 0 1 1
DLS0n0
0/1
Selection of data transfer sequence
0: Inputs/outputs data with MSB first
1: Inputs/outputs data with LSB first.
Setting of data length
0: 7-bit data length
1: 8-bit data length
Selection of the data and clock phase (For
details about the setting, see 12.3 Registers
Controlling Serial Array Unit.)
(c) Serial data register 0n (SDR0nH, SDR0nL)
Symbol: SDR0nH Symbol: SDR0nL
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Baud rate setting
(Operation clock (f
MCK) division setting) 0
Transmit data
(Transmit data setting)
(d) Serial clock output register 0 (CKO0) … Sets only the bits of the target channel.
(Note and Remarks are listed on the next page.)
Symbol: 7 6 5 4 3 2 1 0
CKO0
0 0 0 0 0 0
CKO01
Note
0/1
CKO00
0/1
Communication starts when these bits are 1 if the clock
phase is non-inversion (the CKP0n bit of the SCR0n = 0).
If the clock phase is inverted (CKP0n = 1), communication
starts when these bits are 0.
SIOp
