RL78/G10 CHAPTER 12 SERIAL ARRAY UNIT

R01UH0384EJ0311 Rev. 3.11 321

Dec 22, 2016

(3) Processing flow (in single-reception mode)

Figure 12-34. Timing Chart of Master Reception (in Single-Reception Mode) (Type 1: DAP0n = 0, CKP0n = 0)

SS0n

SE0n

SDR0nL

INTCSIp

TSF0n

ST0n

Receive data 1

SCKp pin

SIp pin

Shift

Data reception

Data reception Data reception

Reception & shift operation

Receive data 3Receive data 2

Receive data 1

Dummy data for reception Dummy data

Dummy data

Receive data 2 Receive data 3

Write

Read

Write

Read

Write

Remark n = 0, 1, p: CSI number (p = 00, 01)
