(1) Register setting
Figure 12-60. Example of Contents of Registers for Slave Transmission/Reception of 3-Wire Serial I/O
(CSI00, CSI01
Note
) (1/2)
(a) Serial mode register 0n (SMR0nH, SMR0nL)
Symbol: SMR0nH Symbol: SMR0nL
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
CKS0n
0/1
CCS0n
1 0 0 0 0 0
STS0n
0 0
SIS0n0
0 1 0 0 0
MD0n1
0
MD0n0
0/1
Interrupt source of channel n
0: Transfer end interrupt
1: Buffer empty interrupt
Operation clock (fMCK) of channel n
0: Prescaler output clock CK00 set by the SPS0 register
1: Prescaler output clock CK01 set by the SPS0 register
(b) Serial communication operation setting register 0n (SCR0nH, SCR0nL)
Symbol: SCR0nH Symbol: SCR0nL
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1
TXE0n
1
RXE0n
1
DAP0n
0/1
CKP0n
0/1 0
EOC0n
0
PTC0n1
0
PTC0n0
0
DIR0n
0/1 0
SLC0n1
0
SLC0n0
0 0 1 1
DLS0n0
0/1
Selection of data transfer sequence
0: Inputs/outputs data with MSB first
1: Inputs/outputs data with LSB first.
Setting of data length
0: 7-bit data length
1: 8-bit data length
Selection of the data and clock
phase (For details about the setting,
see 12.3 Registers Controlling
Serial Array Unit.)
(c) Serial data register 0n (SDR0nH, SDR0nL)
Symbol: SDR0nH Symbol: SDR0nL
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
0000000
Baud rate setting
0
Transmit data setting/receive data register
(d) Serial clock output register 0 (CKO0) … The register that not used in this mode.
(e) Serial output register 0 (SO0) … Sets only the bits of the target channel.
(Note, Caution, and Remarks are listed on the next page.)
Symbol: 7 6 5 4 3 2 1 0
CKO0
0 0 0 0 0 0
CKO01
Note
×
CKO00
×
Symbol: 7 6 5 4 3 2 1 0
SO0
0 0 0 0 0 0
SO01
Note
0/1
SO00
0/1
SIOp
