RL78/G10 CHAPTER 12 SERIAL ARRAY UNIT

R01UH0384EJ0311 Rev. 3.11 381

Dec 22, 2016

(3) Processing flow

Figure 12-81. UART Reception Timing Chart

SS0n

SE0n

SDR0nL

RxDq pin

INTSRq

TSF0n

ST ST

ST0n

Shift

Receive data 1

Receive data 2

Receive data 3

Shift operation

Data reception

Data reception Data reception

Remark n: Channel number (n = 1)

r: Channel number (r = n - 1) q: UART number (q = 0)
