RL78/G10 CHAPTER 13 SERIAL INTERFACE IICA
R01UH0384EJ0311 Rev. 3.11 413
Dec 22, 2016
(11) Start condition generator
This circuit generates a start condition when the STT0 bit is set to 1.
However, in the communication reservation disabled status (IICRSV0 bit = 1), when the bus is not released
(IICBSY0 bit = 1), start condition requests are ignored and the STCF bit is set to 1.
(12) Stop condition generator
This circuit generates a stop condition when the SPT0 bit is set to 1.
(13) Bus status detector
This circuit detects whether or not the bus is released by detecting start conditions and stop conditions.
However, as the bus status cannot be detected immediately following operation, the initial status is set by the
STCEN bit.
Remark STT0 bit: Bit 1 of IICA control register 00 (IICCTL00)
SPT0 bit: Bit 0 of IICA control register 00 (IICCTL00)
IICRSV0 bit: Bit 0 of IICA flag register 0 (IICF0)
IICBSY0 bit: Bit 6 of IICA flag register 0 (IICF0)
STCF0 bit: Bit 7 of IICA flag register 0 (IICF0)
STCEN0 bit: Bit 1 of IICA flag register 0 (IICF0)
