RL78/G10 CHAPTER 13 SERIAL INTERFACE IICA

R01UH0384EJ0311 Rev. 3.11 456

Dec 22, 2016

The main processing of the slave operation is explained next.

Start serial interface IICA and wait until communication is enabled. When communication is enabled, execute

communication by using the communication mode flag and ready flag (processing of the stop condition and start

condition is performed by an interrupt. Here, check the status by using the flags).

The transmission operation is repeated until the master no longer returns ACK. If ACK is not returned from the

master, communication is completed.

For reception, the necessary amount of data is received. When communication is completed, ACK is not returned

as the next data. After that, the master generates a stop condition or restart condition. Exit from the

communication status occurs in this way.
