RL78/G10 CHAPTER 13 SERIAL INTERFACE IICA

R01UH0384EJ0311 Rev. 3.11 474

Dec 22, 2016

(b) When arbitration loss occurs during transmission of extension code

ST AD6 to AD0 R/W ACK D7 to D0 D7 to D0ACK ACK SP

2 1

1: IICS0 = 0110×010B

Sets LREL0 = 1 by software

2: IICS0 = 00000001B

Remark : Always generated

: Generated only when SPIE0 = 1

×: Don’t care

(i) When WTIM0 = 0

ST AD6 to AD0 R/W ACK D7 to D0 D7 to D0ACK ACK SP

3 2 1

1: IICS0 = 10001110B

2: IICS0 = 01000000B

3: IICS0 = 00000001B

Remark : Always generated

: Generated only when SPIE0 = 1
