RL78/G10 CHAPTER 14 INTERRUPT FUNCTIONS

R01UH0384EJ0311 Rev. 3.11 498

Dec 22, 2016

Figure 14-1. Basic Configuration of Interrupt Function (1/2)

(a) Internal maskable interrupt

MK IE PR1 ISP1

PR0

ISP0

Internal bus

Interrupt

request

Priority controller

Vector table

address generator

Standby release

signal

(b) External maskable interrupt (INTPn)

MK IE PR1 ISP1

PR0

ISP0

Internal bus

External interrupt edge

enable register

(EGP0, EGN0)

INTPn pin input

Edge

detector

Priority controller

Vector table

address generator

Standby release

signal

IF: Interrupt request flag

IE: Interrupt enable flag

ISP0: In-service priority flag 0

ISP1: In-service priority flag 1

MK: Interrupt mask flag

PR0: Priority specification flag 0

PR1: Priority specification flag 1

Remark 10-pin product : n = 0, 1

16-pin product : n = 0 to 3
