RL78/G10 CHAPTER 14 INTERRUPT FUNCTIONS

R01UH0384EJ0311 Rev. 3.11 501

Dec 22, 2016

Table 14-4. Flags Corresponding to Interrupt Request Sources (16-pin products)

Interrupt

Source

Interrupt Request Flag Interrupt Mask Flag Priority Specification Flag

INTWDTI WDTIIF IF0L WDTIMK MK0L WDTIPR0 WDTIPR1

PR00L,

PR10L

INTP0 PIF0 PMK0 PPR00 PPR10

INTP1 PIF1 PMK1 PPR01 PPR11

INTST0

Note 1

INTCSI00

Note 1

INTIIC00

Note 1

STIF0

Note 1

CSIIF00

Note 1

IICIF00

Note 1

STMK0

Note 1

CSIMK00

Note 1

IICMK00

Note 1

STPR00 STPR10

Note 1

CSIPR000 CSIPR100

Note 1

IICPR000 IICPR100

Note 1

INTSR0

Note 2

INTCSI01

Note 2

SRIF0

Note 2

CSIIF01

Note 2

SRMK0

Note 2

CSIMK01

Note 2

SRPR00 SRPR10

Note 2

CSIPR001 CSIPR101

Note 2

INTSRE0 SREIF0 SREMK0 SREPR00 SREPR10

INTTM01H TMIF01H TMMK01H TMPR001H TMPR101H

INTTM00 TMIF00 TMMK00 TMPR000 TMPR100

INTTM01 TMIF01 IF0H TMMK01 MK0H TMPR001 TMPR101

PR00H,

PR10H

INTAD ADIF ADMK ADPR0 ADPR1

INTKR KRIF KRMK KRPR0 KRPR1

INTP2 PIF2 PMK2 PPR02 PPR12

INTP3 PIF3 PMK3 PPR03 PPR13

INTTM03H TMIF03H TMMK03H TMPR003H TMPR103H

INTIICA0 IICAIF0 IICAMK0 IICAPR00 IICAPR10

INTTM02 TMIF02 TMMK02 TMPR002 TMPR102

INTTM03 TMIF03 IF1L TMMK03 MK1L TMPR003 TMPR103 PR01L,

PR11L

INTIT ITIF ITMK ITPR0 ITPR1

INTCMP0 CMPIF0 CMPMK0 CMPPR00 CMPPR10

Notes 1. If interrupt source INTST0, INTCSI00, or INTIIC00 occurs, bit 3 of the IF0L register is set to 1.

Bit 3 of the MK0L, PR00L, and PR10L registers supports these three interrupt sources.

2. If interrupt source INTSR0 or INTCSI01 occurs, bit 4 of the IF0L register is set to 1.

Bit 4 of the MK0L, PR00L, and PR10L registers supports these two interrupt sources.
