RL78/G10 CHAPTER 14 INTERRUPT FUNCTIONS
R01UH0384EJ0311 Rev. 3.11 506
Dec 22, 2016
Figure 14-7. Format of Priority Specification Flag Registers (PR00L, PR00H, PR10L, PR10H, PR01L, PR11L)
(16-pin product)
Address: FFFE8H After reset: FFH R/W
Symbol <7> <6> <5> <4> <3> <2> <1> <0>
PR00L TMPR000 TMPR001H SREPR00
SRPR00
CSIPR001
STPR00
CSIPR000
IICPR000
PPR01 PPR00 WDTIPR0
Address: FFFECH After reset: FFH R/W
Symbol <7> <6> <5> <4> <3> <2> <1> <0>
PR10L TMPR100 TMPR101H SREPR10
SRPR10
CSIPR101
STPR10
CSIPR100
IICPR100
PPR11 PPR10 WDTIPR1
Address: FFFE9H After reset: FFH R/W
Symbol <7> <6> <5> <4> <3> <2> <1> <0>
PR00H TMPR002 IICAPR00 TMPR003H PPR03 PPR02 KRPR0 ADPR0 TMPR001
Address: FFFEDH After reset: FFH R/W
Symbol <7> <6> <5> <4> <3> <2> <1> <0>
PR10H TMPR102 IICAPR10 TMPR103H PPR13 PPR12 KRPR1 ADPR1 TMPR101
Address: FFFEAH After reset: FFH R/W
Symbol 7 6 5 4 3 <2> <1> <0>
PR01L 1 1 1 1 1 CMPPR00 ITPR0 TMPR003
Address: FFFEEH After reset: FFH R/W
Symbol 7 6 5 4 3 <2> <1> <0>
PR11L 1 1 1 1 1 CMPPR10 ITPR1 TMPR103
XXPR1X XXPR0X Priority Level Selection
0 0 Specifying level 0 (high priority)
0 1 Specifying level 1
1 0 Specifying level 2
1 1 Specifying level 3 (low priority)
Caution Do not change undefined bit data.
