RL78/G10 CHAPTER 23 INSTRUCTION SET
R01UH0384EJ0311 Rev. 3.11 571
Dec 22, 2016
Table 23-5. Operation List (4/17)
Notes 1. Number of CPU clocks (f
CLK) when the internal RAM area, SFR area, or extended SFR area is accessed, or
when no data is accessed.
2. Number of CPU clocks (f
CLK) when the code flash memory is accessed.
3. Except rp = AX
Remark These numbers of clock cycles apply when the program is in the internal ROM (flash memory) area. When the
instruction is fetched from the internal RAM area, the number is, at most, the quadruple of the number given
here plus 6 further clock cycles.
Instruction
Group
Mnemonic Operands Bytes Clocks Clocks Flag
Note 1 Note 2 ZACCY
8-bit data
transfer
XCH A, [HL+B] 2 2
A ←→ (HL+B)
A, ES:[HL+B] 3 3
A ←→ ((ES, HL)+B)
A, [HL+C] 2 2
A ←→ (HL+C)
A, ES:[HL+C] 3 3
A ←→ ((ES, HL)+C)
ONEB A 1 1
A 01H
X 1 1
X 01H
B 1 1
B 01H
C 1 1
C 01H
!addr16 3 1
(addr16) 01H
ES:!addr16 4 2
(ES, addr16) 01H
saddr 2 1
(saddr) 01H
CLRB A 1 1
A 00H
X 1 1
X 00H
B 1 1
B 00H
C 1 1
C 00H
!addr16 3 1
(addr16) 00H
ES:!addr16 4 2
(ES,addr16) 00H
saddr 2 1
(saddr) 00H
MOVS [HL+byte], X 3 1
(HL+byte) X × ×
ES:[HL+byte], X 4 2
(ES, HL+byte) X × ×
16-bit
data
transfer
MOVW rp, #word 3
2
rp word
saddrp, #word 4 2
(saddrp) word
sfrp, #word 4 2
sfrp word
AX, rp
Note 3
1 2
AX rp
rp, AX
Note 3
1 2
rp AX
AX, !addr16 3 2 5 AX (addr16)
!addr16, AX 3 2
(addr16) AX
AX, ES:!addr16 4 3 6 AX (ES, addr16)
ES:!addr16, AX 4 3
(ES, addr16) AX
AX, saddrp
2 2
AX (saddrp)
saddrp, AX
2 2
(saddrp) AX
AX, sfrp
2 2
AX sfrp
sfrp, AX
2 2
sfrp AX
