Date Code 20130214 Instruction Manual SEL-2414 Transformer Monitor
SEL-2414 Settings Sheets
AIx08 Engr Units (16 characters)
AIx08EU
:=
AIx08 Engr Low (–99999.000 to +99999.000) AIx08EL
:=
AIx08 Engr High (–99999.000 to +99999.000) AIx08EH
:=
AIx08 Low Warn 1 (OFF, –99999.000 to +99999.000) AIx08LW1
:=
AIx08 Low Warn 2 (OFF, –99999.000 to +99999.000) AIx08LW2
:=
AIx08 Low Alarm (OFF, –99999.000 to +99999.000) AIx08LAL
:=
AIx08 Hi Warn 1 (OFF, –99999.000 to +99999.000) AIx08HW1
:=
AIx08 Hi Warn 2 (OFF, –99999.000 to +99999.000) AIx08HW2
:=
AIx08 Hi Alarm (OFF, –99999.000 to +99999.000) AIx08HAL
:=
Analog Output x01 Settings
AOx01 Analog Quantity (Analog Quantity Value) AOx01AQ :=
AOx01 Instrument Tag Name (8 characters 0–9, A–Z, _) AOx01NAM
:=
AOx01 Type (I, V) AOx01TYP
:=
AOx01 Analog Quantity Low (–99999.000 to +99999.000) AOx01AQL
:=
AOx01 Analog Quantity High (–99999.000 to +99999.000) AOx01AQH
:=
If AOx01TYP = I
AOx01 Low Output Value (–20.480 to +20.480 mA) AOx01L
:=
AOx01 High Output (–20.480 to +20.480 mA) AOx01H
:=
If AOx01TYP = V
AOx01 Low Output Value (–10.240 to +10.240 V) AOx01L
:=
AOx01 High Output Value (–10.240 to +10.240 V) AOx01H
:=
Analog Output x02 Settings
AOx02 Analog Quantity (Analog Quantity Value) AOx02AQ :=
AOx02 Instrument Tag Name (8 characters 0–9, A–Z, _) AOx02NAM
:=
AOx02 Type (I, V) AOx02TYP
:=
AOx02 Analog Quantity Low (–99999.000 to +99999.000) AOx02AQL
:=
AOx02 Analog Quantity High (–99999.000 to +99999.000) AOx02AQH
:=
If AOx02TYP = I
AOx02 Low Output Value (–20.480 to +20.480 mA) AOx02L
:=
AOx02 High Output (–20.480 to +20.480 mA) AOx02H
:=
If AOx02TYP = V
AOx02 Low Output Value (–10.240 to +10.240 V) AOx02L
:=
AOx02 High Output Value (–10.240 to +10.240 V) AOx02H
:=
Analog Output x03 Settings
AOx03 Analog Quantity (Analog Quantity Value) AOx03AQ :=
AOx03 Instrument Tag Name (8 characters 0–9, A–Z, _) AOx03NAM
:=
AOx03 Type (I, V) AOx03TYP
:=
AOx03 Analog Quantity Low (–99999.000 to +99999.000) AOx03AQL
:=
AOx03 Analog Quantity High (–99999.000 to +99999.000) AOx03AQH
:=
If AOx03TYP = I
AOx03 Low Output Value (–20.480 to +20.480 mA) AOx03L
:=
AOx03 High Output (–20.480 to +20.480 mA) AOx03H
:=
If AOx03TYP = V
AOx03 Low Output Value (–10.240 to +10.240 V) AOx03L
:=
AOx03 High Output Value (–10.240 to +10.240 V) AOx03H
:=
