SEL-2414 Transformer Monitor Instruction Manual Date Code 20130214
SEL-2414 Settings Sheets
Analog Output x04 Settings
AOx04 Analog Quantity (Analog Quantity Value) AOx04AQ :=
AOx04 Instrument Tag Name (8 characters 0–9, A–Z, _) AOx04NAM
:=
AOx04 Type (I, V) AOx04TYP
:=
AOx04 Analog Quantity Low (–99999.000 to +99999.000) AOx04AQL
:=
AOx04 Analog Quantity High (–99999.000 to +99999.000) AOx04AQH
:=
If AOx04TYP = I
AOx04 Low Output Value (–20.480 to +20.480 mA) AOx04L
:=
AOx04 High Output (–20.480 to +20.480 mA) AOx04H
:=
If AOx04TYP = V
AOx04 Low Output Value (–10.240 to +10.240 V) AOx04L
:=
AOx04 High Output Value (–10.240 to +10.240 V) AOx04H
:=
Internal RTD
RTD1 TYPE (PT100, NI100, NI120, CU10, NONE) IRTD1TY :=
RTD2 TYPE (PT100, NI100, NI120, CU10, NONE) IRTD2TY
:=
RTD3 TYPE (PT100, NI100, NI120, CU10, NONE) IRTD3TY
:=
RTD4 TYPE (PT100, NI100, NI120, CU10, NONE) IRTD4TY
:=
RTD5 TYPE (PT100, NI100, NI120, CU10, NONE) IRTD5TY
:=
RTD6 TYPE (PT100, NI100, NI120, CU10, NONE) IRTD6TY
:=
RTD7 TYPE (PT100, NI100, NI120, CU10, NONE) IRTD7TY
:=
RTD8 TYPE (PT100, NI100, NI120, CU10, NONE) IRTD8TY
:=
RTD9 TYPE (PT100, NI100, NI120, CU10, NONE) IRTD9TY
:=
RTD10 TYPE (PT100, NI100, NI120, CU10, NONE) IRTD10TY
:=
External RTD Via SEL-2600 Devices
RTD1 TYPE (PT100, NI100, NI120, CU10, NONE) ERTD1TY :=
RTD2 TYPE (PT100, NI100, NI120, CU10, NONE) ERTD2TY
:=
RTD3 TYPE (PT100, NI100, NI120, CU10, NONE) ERTD3TY
:=
RTD4 TYPE (PT100, NI100, NI120, CU10, NONE) ERTD4TY
:=
RTD5 TYPE (PT100, NI100, NI120, CU10, NONE) ERTD5TY
:=
RTD6 TYPE (PT100, NI100, NI120, CU10, NONE) ERTD6TY
:=
RTD7 TYPE (PT100, NI100, NI120, CU10, NONE) ERTD7TY
:=
RTD8 TYPE (PT100, NI100, NI120, CU10, NONE) ERTD8TY
:=
RTD9 TYPE (PT100, NI100, NI120, CU10, NONE) ERTD9TY
:=
RTD10 TYPE (PT100, NI100, NI120, CU10, NONE) ERTD10TY
:=
RTD11 TYPE (PT100, NI100, NI120, CU10, NONE) ERTD11TY
:=
RTD12 TYPE (PT100, NI100, NI120, CU10, NONE) ERTD12TY
:=
RTD/TC from Universal Temperature Input Card
TEMP1 TYPE
(PT100, NI100, NI120, CU10, J, K, T, E, NONE)
INTEMP01 :=
TEMP2 TYPE
(PT100, NI100, NI120, CU10, J, K, T, E, NONE)
INTEMP02
:=
TEMP3 TYPE
(PT100, NI100, NI120, CU10, J, K, T, E, NONE)
INTEMP03
:=
TEMP4 TYPE
(PT100, NI100, NI120, CU10, J, K, T, E, NONE)
INTEMP04
:=
TEMP5 TYPE
(PT100, NI100, NI120, CU10, J, K, T, E, NONE)
INTEMP05
:=
TEMP6 TYPE
(PT100, NI100, NI120, CU10, J, K, T, E, NONE)
INTEMP06
:=
