SEL-2414 Transformer Monitor Instruction Manual Date Code 20130214
SEL-2414 Settings Sheets
Logic Settings (SET L Command)
Global Settings (SET G Command)
General Settings
Phase Rotation (ABC, ACB) PHROT :=
Rated Frequency (50, 60 Hz) FNOM
:=
Transformer Connection (DELTA, WYE) DELTA_Y
:=
Date Format (MDY, YMD, DMY) DATE_F
:=
Input Debounce Settings (Base Unit)
IN101 Debounce (AC, 0–65000 ms) IN101D :=
IN102 Debounce (AC, 0–65000 ms) IN102D
:=
Input Debounce Settings (Slot 3)
IN301 Debounce (AC, 0–65000 ms) IN301D :=
IN302 Debounce (AC, 0–65000 ms) IN302D
:=
IN303 Debounce (AC, 0–65000 ms) IN303D
:=
IN304 Debounce (AC, 0–65000 ms) IN304D
:=
IN305 Debounce (AC, 0–65000 ms) IN305D
:=
IN306 Debounce (AC, 0–65000 ms) IN306D
:=
IN307 Debounce (AC, 0–65000 ms) IN307D
:=
IN308 Debounce (AC, 0–65000 ms) IN308D
:=
Input Debounce Settings (Slot 4)
IN401 Debounce (AC, 0–65000 ms) IN401D :=
IN402 Debounce (AC, 0–65000 ms) IN402D
:=
IN403 Debounce (AC, 0–65000 ms) IN403D
:=
IN404 Debounce (AC, 0–65000 ms) IN404D
:=
IN405 Debounce (AC, 0–65000 ms) IN405D
:=
IN406 Debounce (AC, 0–65000 ms) IN406D
:=
IN407 Debounce (AC, 0–65000 ms) IN407D
:=
IN408 Debounce (AC, 0–65000 ms) IN408D
:=
Input Debounce Settings (Slot 5)
IN501 Debounce (AC, 0–65000 ms) IN501D :=
IN502 Debounce (AC, 0–65000 ms) IN502D
:=
IN503 Debounce (AC, 0–65000 ms) IN503D
:=
IN504 Debounce (AC, 0–65000 ms) IN504D
:=
IN505 Debounce (AC, 0–65000 ms) IN505D
:=
IN506 Debounce (AC, 0–65000 ms) IN506D
:=
IN507 Debounce (AC, 0–65000 ms) IN507D
:=
IN508 Debounce (AC, 0–65000 ms) IN508D
:=
