SEL-2414 Transformer Monitor Instruction Manual Date Code 20130214
SEL-2414 Settings Sheets
Logic Settings (SET L Command)
DNP3 Settings (SET DNP Command)
Serial Port Settings
Minimum delay from DCD to TX, seconds (0.00–1.00) MINDLY :=
Maximum delay from DCD to TX, seconds (0.00–1.00) MAXDLY
:=
Settle time from RTS on to TX; Off disables PSTDLY (OFF, 0.00–30.00) PREDLY
:=
Settle time from TX to RTS off (0.00–30.00) PSTDLY
:=
Serial Modem Settings
Modem connected to port (Y, N) MODEM :=
Modem startup string (Up to 30 characters) MSTR
:=
Primary phone number for dial-out (Up to 30 characters) PH_NUM1
:=
Secondary phone number for dial-out (Up to 30 characters) PH_NUM2
:=
Retry attempts for primary dial-out (1–20) RETRY1
:=
Retry attempts for secondary dial-out (1–20) RETRY2
:=
Time from initiating call to failure due to no connection, seconds (5–300) MDTIME
:=
Time between dial-out attempts (5–3600) MDRET
:=
DNP Binary Input Label name (10 characters) BI_00
•
•
•
BI_99
DNP Binary Output Label Name (10 characters) BO_00
•
•
•
BO_31
DNP Analog Input Label Name (10 characters) AI_00
•
•
•
AO_31
DNP Analog Input Label Name (10 characters) CO_00
•
•
•
CO_31
