Date Code 20130214 Instruction Manual SEL-2414 Transformer Monitor
SEL-2414 Settings Sheets
Logic Settings (SET L Command)
DNP3 Session Map (1–3) DNPMAP2 :=
Analog Input Default Variation (0–6) DVARAI2
:=
Class for binary event data, 0 disables (0–3) ECLASSB2
:=
Class for counter event data, 0 disables (0–3) ECLASSC2
:=
Class for analog event data, 0 disables (0–3) ECLASSA2
:=
Decimal places scaling for Current data (0–3) DECPLA2
:=
Decimal places scaling for Voltage data (0–3) DECPLV2
:=
Decimal places scaling for Miscellaneous data (0–3) DECPLM2
:=
Analog reporting dead band for current (0–32767) ANADBA2
:=
Analog reporting dead band for voltages (0–32767) ANADBV2
:=
Analog reporting dead band for miscellaneous analogs (0–32767) ANADBM2
:=
Time-set request interval, minutes (I, M, 1–32767) TIMERQ2
:=
Select/operate time-out, seconds (0.0–30.0) STIMEO2
:=
Send Data Link Heartbeat, seconds (0.0–7200) DNPINA2
:=
Data link retries (0–15) DRETRY2
:=
Data link time-out, seconds (0.0–5.0) DTIMEO2
:=
Event message confirm time-out, seconds (1–50) ETIMEO2
:=
Enable unsolicited reporting (Y, N) UNSOL2
:=
Enable unsolicited reporting at power up (Y, N) PUNSOL2
:=
Number of events to transmit on (1–200) NUMEVE2
:=
Oldest event to transmit on, seconds (0.0–99999.0) AGEEVE2
:=
Unsolicited messages maximum retry attempts (2–10) URETRY2
:=
Unsolicited messages offline timeout, seconds (1–5000) UTIMEO2
:=
Session 3 Settings
IP Address (zzz.yyy.xxx.www) DNPIP3 :=
Transport Protocol (UDP, TCP) DNPTR3
:=
UDP Response Port (REQ, 1–65534) DNPUDP3
:=
DNP3 address of the Master to send messages to (0–65519) REPADR3
:=
DNP3 Session Map (1–3) DNPMAP3
:=
Analog Input Default Variation (0–6) DVARAI3
:=
Class for binary event data, 0 disables (0–3) ECLASSB3
:=
Class for counter event data, 0 disables (0–3) ECLASSC3
:=
Class for analog event data, 0 disables (0–3) ECLASSA3
:=
Decimal places scaling for Current data (0–3) DECPLA3
:=
Decimal places scaling for Voltage data (0–3) DECPLV3
:=
Decimal places scaling for Miscellaneous data (0–3) DECPLM3
:=
Analog reporting dead band for current (0–32767) ANADBA3
:=
Analog reporting dead band for voltages (0–32767) ANADBV3
:=
Analog reporting dead band for miscellaneous analogs (0–32767) ANADBM3
:=
Time-set request interval, minutes (I, M, 1–32767) TIMERQ3
:=
Select/operate time-out, seconds (0.0–30.0) STIMEO3
:=
Send Data Link Heartbeat, seconds (0.0–7200) DNPINA3
:=
Data link retries (0–15) DRETRY3
:=
Data link time-out, seconds (0.0–5.0) DTIMEO3
:=
Event message confirm time-out, seconds (1–50) ETIMEO3
:=
Enable unsolicited reporting (Y, N) UNSOL3
:=
Enable unsolicited reporting at power up (Y, N) PUNSOL3
:=
Number of events to transmit on (1–200) NUMEVE3
:=
Oldest event to transmit on, seconds (0.0–99999.0) AGEEVE3
:=
Unsolicited messages maximum retry attempts (2–10) URETRY3
:=
Unsolicited messages offline timeout, seconds (1–5000) UTIMEO3
:=
