SET.26
of 36
SEL-2414 Transformer Monitor Instruction Manual Date Code 20130214
SEL-2414 Settings Sheets
Logic Settings (SET L Command)
RMB7 Dropout Debounce Messages (1–8) RMB7DO :=
RMB8 Pickup Debounce Messages (1–8) RMB8PU
:=
RMB8 Dropout Debounce Messages (1–8) RMB8DO
:=
Telnet
Telnet Port (23, 1025–65534) TPORT :=
Telnet Port Timeout (1–30 min) TIDLE
:=
File Transfer User Name (20 characters) FTPUSER
:=
IP Address [zzz.yyy.xxx.www] (15 characters) IPADDR
:=
Subnet Mask (15 characters) SUBNETM
:=
Default Router Gateway (15 characters) DEFRTR
:=
DNP3 Communications (Hidden if DNP not supported)
Enable DNP Sessions (0–3) EDNP :=
DNP TCP and UDP Port (1–65534) DNPNUM
:=
Device DNP Address (0–65519) DNPADR
:=
Session 1 Settings
IP Address (zzz.yyy.xxx.www) DNPIP1 :=
Transport Protocol (UDP, TCP) DNPTR1
:=
UDP Response Port (REQ, 1–65534) DNPUDP1
:=
DNP3 address of the Master to send messages to (0–65519) REPADR1
:=
DNP3 Session Map (1–3) DNPMAP1
:=
Analog Input Default Variation (0–6) DVARAI1
:=
Class for binary event data, 0 disables (0–3) ECLASSB1
:=
Class for counter event data, 0 disables (0–3) ECLASSC1
:=
Class for analog event data, 0 disables (0–3) ECLASSA1
:=
Decimal places scaling for Current data (0–3) DECPLA1
:=
Decimal places scaling for Voltage data (0–3) DECPLV1
:=
Decimal places scaling for Miscellaneous data (0–3) DECPLM1
:=
Analog reporting dead band for current (0–32767) ANADBA1
:=
Analog reporting dead band for voltages (0–32767) ANADBV1
:=
Analog reporting dead band for miscellaneous analogs (0–32767) ANADBM1
:=
Time–set request interval, minutes (I, M, 1–32767) TIMERQ1
:=
Select/operate time-out, seconds (0.0–30.0) STIMEO1
:=
Send Data Link Heartbeat, seconds (0.0–7200) DNPINA1
:=
Data link retries (0–15) DRETRY1
:=
Data link time-out, seconds (0.0–5.0) DTIMEO1
:=
Event message confirm time-out, seconds (1–50) ETIMEO1
:=
Enable unsolicited reporting (Y, N) UNSOL1
:=
Enable unsolicited reporting at power up (Y, N) PUNSOL1
:=
Number of events to transmit on (1–200) NUMEVE1
:=
Oldest event to transmit on, seconds (0.0–99999.0) AGEEVE1
:=
Unsolicited messages maximum retry attempts (2–10) URETRY1
:=
Unsolicited messages offline timeout, seconds (1–5000) UTIMEO1
:=
Session 2 Settings
IP Address (zzz.yyy.xxx.www) DNPIP2 :=
Transport Protocol (UDP, TCP) DNPTR2
:=
UDP Response Port (REQ, 1–65534) DNPUDP2
:=
DNP3 address of the Master to send messages to (0–65519) REPADR2
:=
