Date Code 20130214 Instruction Manual SEL-2414 Transformer Monitor
SEL-2414 Settings Sheets
Logic Settings (SET L Command)
Minutes to Port Timeout (1–30 min) T_OUT :=
Send Auto Message (Y, N) AUTO
:=
Fast Operate Messages (Y, N) FASTOP
:=
Port 3
Port Enable (Y, N) EPORT :=
Maximum Access Level (ACC, 2AC) MAXACC
:=
Protocol (SEL, DNP, MOD, MBA, MBB, MB8A, MB8B, MBTA, MBTB,
EVMSG, RTD)
PROTO
:=
Speed (300 to 38400 bps) SPEED
:=
Data Bits (7, 8 bits) BITS
:=
Parity (O, E, N) PARITY
:=
Stop Bits (1, 2 bits) STOP
:=
Minutes to Port Timeout (1–30 min) T_OUT
:=
Send Auto Message (Y, N) AUTO
:=
Enable Hardware Handshaking (Y, N) RTSCTS
:=
Fast Operate Messages (Y, N) FASTOP
:=
Port 4
Port Enable (Y, N) EPORT :=
Maximum Access Level (ACC, 2AC) MAXACC
:=
Communication Interface (232, 485) COMMINF
:=
Protocol (SEL, DNP, MOD, MBA, MBB, MB8A, MB8B, MBTA, MBTB,
EVMSG, RTD)
PROTO
:=
Speed (300 to 38400 bps) SPEED
:=
Data Bits (7, 8 bits) BITS
:=
Parity (O, E, N) PARITY
:=
Stop Bits (1, 2 bits) STOP
:=
Minutes to Port Timeout (1–30 min) T_OUT
:=
Send Auto Message (Y, N) AUTO
:=
Enable Hardware Handshaking (Y, N) RTSCTS
:=
Fast Operate Messages (Y, N) FASTOP
:=
MIRRORED BITS
MB Transmit Identifier (1–4) TXID :=
MB Receive Identifier (1–4) RXID
:=
MB RX Bad Pickup Time (0–10000 seconds) RBADPU
:=
PPM MB Channel Bad Pickup (1–10000) CBADPU
:=
MB Receive Default State (8 character string of 1s, 0s, or Xs) RXDFLT
:=
RMB1 Pickup Debounce Messages (1–8) RMB1PU
:=
RMB1 Dropout Debounce Messages (1–8) RMB1DO
:=
RMB2 Pickup Debounce Messages (1–8) RMB2PU
:=
RMB2 Dropout Debounce Messages (1–8) RMB2DO
:=
RMB3 Pickup Debounce Messages (1–8) RMB3PU
:=
RMB3 Dropout Debounce Messages (1–8) RMB3DO
:=
RMB4 Pickup Debounce Messages (1–8) RMB4PU
:=
RMB4 Dropout Debounce Messages (1–8) RMB4DO
:=
RMB5 Pickup Debounce Messages (1–8) RMB5PU
:=
RMB5 Dropout Debounce Messages (1–8) RMB5DO
:=
RMB6 Pickup Debounce Messages (1–8) RMB6PU
:=
RMB6 Dropout Debounce Messages (1–8) RMB6DO
:=
RMB7 Pickup Debounce Messages (1–8) RMB7PU
:=
