SEL-2414 Transformer Monitor Instruction Manual Date Code 20130214
SEL-2414 Settings Sheets
Logic Settings (SET L Command)
Port Settings (SET P Command)
Port F
Port Enable (Y, N) EPORT :=
Maximum Access Level (ACC, 2AC) MAXACC
:=
Speed (300 to 38400 bps) SPEED
:=
Data Bits (7, 8 bits) BITS
:=
Parity (O, E, N) PARITY
:=
Stop Bits (1, 2 bits) STOP
:=
Port Timeout (1–30 min) T_OUT
:=
Send Auto Message (Y, N) AUTO
:=
Hardware Handshaking (Y, N) RTSCTS
:=
Fast Operate Messages (Y, N) FASTOP
:=
Port 1 (Ethernet Port in Slot B)
All Ethernet settings are hidden if an Ethernet option is not available.
Port Enable (Y, N) EPORT
:=
Maximum Access Level (ACC, 2AC) MAXACC
:=
IP ADDRESS (zzz.yyy.xxx.www) IPADDR
:=
SUBNET MASK( zzz.yyy.xxx.www) SUBNETM
:=
DEFAULT ROUTER (zzz.yyy.xxx.www) DEFRTR
:=
Enable TCP Keep-Alive (Y, N) ETCPKA
:=
TCP Keep-Alive Idle Range (1–20 sec) (
Hidden if ETCPKA := N) KAIDLE :=
TCP Keep-Alive Interval Range (1–20 sec) (
Hidden if ETCPKA := N) KAINTV :=
TCP Keep-Alive Count Range (1–20 sec) (
Hidden if ETCPKA := N) KACNT :=
OPERATING MODE (Fixed, Failover, Switched)
(
Hidden if not dual redundant Ethernet port option)
NETMODE :=
FAILOVER TIMEOUT (0.10–65.00 sec)
(
Hidden if not dual redundant Ethernet port option or if NETMODE is not FAILOVER)
FTIME
:=
PRIMARY NET PORT (A, B, D)
(
Hidden if not dual redundant Ethernet port option)
NETPORT
:=
NETWRK PORTA SPD (Auto, 10, 100 Mbps) NETASPD
:=
NETWRK PORTB SPD (Auto, 10, 100 Mbps)
(
Hidden if not dual redundant Ethernet port option)
NETBSPD :=
Enable Telnet (Y,N) ETELNET
:= Y
TELNET PORT (23,1025–65534) TPORT
:=
TELNET TIME-OUT (1–30 min) TIDLE
:=
Enable FTP (Y,N) EFTP
:= Y
FTP USER NAME (20 characters) FTPUSER
:=
Enable Modbus (Y,N) EMODBUS
:= Y
Enable IEC 61850 Protocol (Y, N) (
Hidden if 61850 not supported) E61850 :=
Enable IEC 61850 GSE (Y, N) (
Hidden if E61850 := N) EGSE :=
Enable DNP Sessions (
Hidden if DNP not supported) EDNP :=
Port 2
Port Enable (Y, N) EPORT :=
Maximum Access Level (ACC, 2AC) MAXACC
:=
Protocol (SEL, DNP, MOD, MBA, MBB, MB8A, MB8B, MBTA, MBTB,
EVMSG, RTD)
PROTO
:=
Speed (300 to 38400 bps) SPEED
:=
Data Bits (7, 8 bits) BITS
:=
Parity (O, E, N) PARITY
:=
Stop Bits (1, 2 bits) STOP
:=
