Firmware and Manual Versions
Instruction Manual
Section 8
➤ Added description of lower pushbutton LED functionality and settings.
Appendix A
➤ Updated for firmware version R303.
20100512
Section 1
➤ Added surface mount ordering option.
Section 2
➤ Added surface mount option dimensional drawings.
20100115
Section 1
➤ Added Universal Temperature Input card to Table 1.1: Slot Allocations for Different Option Cards.
➤ Added Universal Temperature Input card specifications, and updated RTD Input card specifications.
Section 2
➤ Added Universal Temperature Input card to Table 2.1: Slot Allocations for Different Option Cards.
➤ Added Thermocouple Inputs description and calibration procedure.
➤ Updated RTD Input description section.
Section 4
➤ Added DNP setting category in Table 4.1: Setting Categories.
➤ Updated Math Variable description.
Section 5
➤ Added Thermal Metering meter MET TEMP command.
Section 6
➤ Added Table 6.12: Input Settings for Internal General Purpose RTD/TC Card in Slot 2.
Settings Sheets
➤ Added Universal Temperature Card input settings.
➤ Removed Display Point default settings.
Section 7
➤ Updated Table 7.1: Communications Port Physical Interfaces.
Section 8
➤ Corrected front panel pictures.
Appendix A
➤ Updated for firmware version R302.
Appendix E
➤ Corrected Address numbers in Table E.4: 02h Input Status/Register.
➤ Clarified 03h, 04h, 05h, 06h, and 10h instruction descriptions.
20090624
Appendix A
➤ Updated for Analog Quantities and Device Word Bit firmware version R207.
20090311
Appendix A
➤ Added information on thermal monitor and through-fault monitor capabilities throughout the manual.
➤ Revised entire manual to improve explanations and consolidate information.
20081111
Appendix A
➤ Updated for Ethernet card firmware version R205.
20081030
Appendix A
➤ Updated for Ethernet card firmware version R204.
