Date Code 20130214 Instruction Manual SEL-2414 Transformer Monitor
DNP3 Communications
DNP3 in the SEL-2414
Use Table D.9 for R303 and later.
Table D.8 R302 or Previous Example Object 12 Trip/Close or Code Selection Operation
Control
Points
Trip / Close Code Selection Operation
Close (0x4X) Trip (0x8X) Latch On (3) Latch Off (4) Pulse On (1) Pulse Off (2)
RB01:RB02 PULSE ON RB02 PULSE ON RB01 PULSE ON RB02 PULSE ON RB01 PULSE ON RB02 PULSE ON
RB01
RB03 SET RB03 CLEAR RB03 SET RB03 CLEAR RB03 SET RB03 CLEAR RB03
RB04 SET RB04 CLEAR RB04 SET RB04 CLEAR RB04 SET RB04 CLEAR RB04
RB05:RB06 PULSE ON RB06 PULSE ON RB05 PULSE ON RB06 PULSE ON RB05 PULSE ON RB06 PULSE ON
RB05
RB07 SET RB07 CLEAR RB07 SET RB07 CLEAR RB07 SET RB07 CLEAR RB07
RB08 SET RB08 CLEAR RB08 SET RB08 CLEAR RB08 SET RB08 CLEAR RB08
RB14:RB15 PULSE ON RB15 PULSE ON RB14 PULSE ON RB15 PULSE ON RB14 PULSE ON RB15 PULSE ON
RB14
RB18:RB21 PULSE ON RB21 PULSE ON RB18 PULSE ON RB21 PULSE ON RB18 PULSE ON RB21 PULSE ON
RB18
Table D.9 R303 or Later Example Object 12 Trip/Close or Code Selection Operation
Control Points
Trip/Close Code Selection Operation
Close/PULSE_ON Trip/PULSE_ON Null/LATCH_ON Null/LATCH_OFF Null/PULSE_ON
RB01:RB02 PULSE ON RB02 PULSE ON RB01 NOT_SUPPORTED NOT_SUPPORTED NOT_SUPPORTED
RB03 PULSE ON RB03 PULSE ON RB03 SET RB03 CLEAR RB03 PULSE ON RB03
