E.15
Date Code 20130214 Instruction Manual SEL-2414 Transformer Monitor
Modbus Communications
Modbus Register Map
510 1FE 03h, 04h 0 Event AO601—LW EU
511 1FF 03h, 04h 16 –2147483648 +2147483647 0 Event AO602—UW EU
512 200 03h, 04h 0 Event AO602—LW EU
513 201 03h, 04h 16 –2147483648 +2147483647 0 Event AO603—UW EU
514 202 03h, 04h 0 Event AO603—LW EU
515 203 03h, 04h 16 –2147483648 +2147483647 0 Event AO604—UW EU
516 204 03h, 04h 0 Event AO604—LW EU
517 205 03h, 04h 1 0 65535 0 Event IAX A
518 206 03h, 04h 1 0 65535 0 Event IBX A
519 207 03h, 04h 1 0 65535 0 Event ICX A
520–549 208–225 03h, 04h 5 8000 8000 8000 Reserved = 8000 Hex
Analog Inputs
550 226 03h, 04h 16 –2147483648 +2147483648 0 AI301—UW EU
551 227 03h, 04h 0 AI301—LW EU
552 228 03h, 04h 16 –2147483648 +2147483648 0 AI302—UW EU
553 229 03h, 04h 0 AI302—LW EU
554 22A 03h, 04h 16 –2147483648 +2147483648 0 AI303—UW EU
555 22B 03h, 04h 0 AI303—LW EU
556 22C 03h, 04h 16 –2147483648 +2147483648 0 AI304—UW EU
557 22D 03h, 04h 0 AI304—LW EU
558 22E 03h, 04h 16 –2147483648 +2147483648 0 AI305—UW EU
559 22F 03h, 04h 0 AI305—LW EU
560 230 03h, 04h 16 –2147483648 +2147483648 0 AI306—UW EU
561 231 03h, 04h 0 AI306—LW EU
562 232 03h, 04h 16 –2147483648 +2147483648 0 AI307—UW EU
563 233 03h, 04h 0 AI307—LW EU
564 234 03h, 04h 16 –2147483648 +2147483648 0 AI308—UW EU
565 235 03h, 04h 0 AI308—LW EU
566 236 03h, 04h 16 –2147483648 +2147483648 0 AI401—UW EU
567 237 03h, 04h 0 AI401—LW EU
568 238 03h, 04h 16 –2147483648 +2147483648 0 AI402—UW EU
569 239 03h, 04h 0 AI402—LW EU
570 23A 03h, 04h 16 –2147483648 +2147483648 0 AI403—UW EU
571 23B 03h, 04h 0 AI403—LW EU
572 23C 03h, 04h 16 –2147483648 +2147483648 0 AI404—UW EU
573 23D 03h, 04h 0 AI404—LW EU
574 23E 03h, 04h 16 –2147483648 +2147483648 0 AI405—UW EU
575 23F 03h, 04h 0 AI405—LW EU
576 240 03h, 04h 16 –2147483648 +2147483648 0 AI406—UW EU
577 241 03h, 04h 0 AI406—LW EU
Table E.15 Modbus Register Map (Sheet 9 of 25)
Address in
Decimal
Address
in Hex
Function
Code
Supported
Conversion Min Max Default Name/Enums Units
