E.16
SEL-2414 Transformer Monitor Instruction Manual Date Code 20130214
Modbus Communications
Modbus Register Map
578 242 03h, 04h 16 –2147483648 +2147483648 0 AI407—UW EU
579 243 03h, 04h 0 AI407—LW EU
580 244 03h, 04h 16 –2147483648 +2147483648 0 AI408—UW EU
581 245 03h, 04h 0 AI408—LW EU
582 246 03h, 04h 16 –2147483648 +2147483648 0 AI501—UW EU
583 247 03h, 04h 0 AI501—LW EU
584 248 03h, 04h 16 –2147483648 +2147483648 0 AI502—UW EU
585 249 03h, 04h 0 AI502—LW EU
586 24A 03h, 04h 16 –2147483648 +2147483648 0 AI503—UW EU
587 24B 03h, 04h 0 AI503—LW EU
588 24C 03h, 04h 16 –2147483648 +2147483648 0 AI504—UW EU
589 24D 03h, 04h 0 AI504—LW EU
590 24E 03h, 04h 16 –2147483648 +2147483648 0 AI505—UW EU
591 24F 03h, 04h 0 AI505—LW EU
592 250 03h, 04h 16 –2147483648 +2147483648 0 AI506—UW EU
593 251 03h, 04h 0 AI506—LW EU
594 252 03h, 04h 16 –2147483648 +2147483648 0 AI507—UW EU
595 253 03h, 04h 0 AI507—LW EU
596 254 03h, 04h 16 –2147483648 +2147483648 0 AI508—UW EU
597 255 03h, 04h 0 AI508—LW EU
598 256 03h, 04h 16 –2147483648 +2147483648 0 AI601—UW EU
599 257 03h, 04h 0 AI601—LW EU
600 258 03h, 04h 16 –2147483648 +2147483648 0 AI602—UW EU
601 259 03h, 04h 0 AI602—LW EU
602 25A 03h, 04h 16 –2147483648 +2147483648 0 AI603—UW EU
603 25B 03h, 04h 0 AI603—LW EU
604 25C 03h, 04h 16 –2147483648 +2147483648 0 AI604—UW EU
605 25D 03h, 04h 0 AI604—LW EU
606 25E 03h, 04h 16 –2147483648 +2147483648 0 AI605—UW EU
607 25F 03h, 04h 0 AI605—LW EU
608 260 03h, 04h 16 –2147483648 +2147483648 0 AI606—UW EU
609 261 03h, 04h 0 AI606—LW EU
610 262 03h, 04h 16 –2147483648 +2147483648 0 AI607—UW EU
611 263 03h, 04h 0 AI607—LW EU
612 264 03h, 04h 16 –2147483648 +2147483648 0 AI608—UW EU
613 265 03h, 04h 0 AI608—LW EU
614–649 266–289 03h, 04h 5 8000 8000 8000 Reserved = 8000 Hex
Table E.15 Modbus Register Map (Sheet 10 of 25)
Address in
Decimal
Address
in Hex
Function
Code
Supported
Conversion Min Max Default Name/Enums Units
To Next Page
