E.17
Date Code 20130214 Instruction Manual SEL-2414 Transformer Monitor
Modbus Communications
Modbus Register Map
RTDs
Values for RTDs
Typically –50 to 250°C
0x7FFF Open
0x8000 Short
0x7FFC Comm
Fail
0x7FF8 Stat Fail
0x7FFE Fail
0x7FF0 Not
Attached
650 28A 03h, 04h 1 –32768 32767 0 INTRTD01 deg C
651 28B 03h, 04h 1 –32768 32767 0 INTRTD02 deg C
652 28C 03h, 04h 1 –32768 32767 0 INTRTD03 deg C
653 28D 03h, 04h 1 –32768 32767 0 INTRTD04 deg C
654 28E 03h, 04h 1 –32768 32767 0 INTRTD05 deg C
655 28F 03h, 04h 1 –32768 32767 0 INTRTD06 deg C
656 290 03h, 04h 1 –32768 32767 0 INTRTD07 deg C
657 291 03h, 04h 1 –32768 32767 0 INTRTD08 deg C
658 292 03h, 04h 1 –32768 32767 0 INTRTD09 deg C
659 293 03h, 04h 1 –32768 32767 0 INTRTD10 deg C
660 294 03h, 04h 1 –32768 32767 0 EXTRTD01 deg C
661 295 03h, 04h 1 –32768 32767 0 EXTRTD02 deg C
662 296 03h, 04h 1 –32768 32767 0 EXTRTD03 deg C
663 297 03h, 04h 1 –32768 32767 0 EXTRTD04 deg C
664 298 03h, 04h 1 –32768 32767 0 EXTRTD05 deg C
665 299 03h, 04h 1 –32768 32767 0 EXTRTD06 deg C
666 29A 03h, 04h 1 –32768 32767 0 EXTRTD07 deg C
667 29B 03h, 04h 1 –32768 32767 0 EXTRTD08 deg C
668 29C 03h, 04h 1 –32768 32767 0 EXTRTD09 deg C
669 29D 03h, 04h 1 –32768 32767 0 EXTRTD10 deg C
670 29E 03h, 04h 1 –32768 32767 0 EXTRTD11 deg C
671 29F 03h, 04h 1 –32768 32767 0 EXTRTD12 deg C
672 2A0 03h, 04h 6 –32768 32767 0 INTEMP01 deg C
673 2A1 03h, 04h 1 –32767 32767 0 INTEMP02 deg C
674 2A2 03h, 04h 1 –32768 32767 0 INTEMP03 deg C
675 2A3 03h, 04h 1 –32768 32767 0 INTEMP04 deg C
676 2A4 03h, 04h 1 –32768 32767 0 INTEMP05 deg C
677 2A5 03h, 04h 1 –32768 32767 0 INTEMP06 deg C
678 2A6 03h, 04h 1 –32768 32767 0 INTEMP07 deg C
Table E.15 Modbus Register Map (Sheet 11 of 25)
Address in
Decimal
Address
in Hex
Function
Code
Supported
Conversion Min Max Default Name/Enums Units
