E.18
SEL-2414 Transformer Monitor Instruction Manual Date Code 20130214
Modbus Communications
Modbus Register Map
679 2A7 03h, 04h 1 –32768 32767 0 INTEMP08 deg C
680 2A8 03h, 04h 1 –32768 32767 0 INTEMP09 deg C
681 2A9 03h, 04h 1 –32768 32767 0 INTEMP10 deg C
682–699 2AA–
2BB
03h, 04h 5 8000 8000 8000 Reserved = 8000 Hex
Math Variables
700 2BC 03h, 04h 15 –1677721599 +1677721599 0 MV01—UW
701 2BD 03h, 04h 0 MV01—LW
702 2BE 03h, 04h 15 –1677721599 +1677721599 0 MV02—UW
703 2BF 03h, 04h 0 MV02—LW
704 2C0 03h, 04h 15 –1677721599 +1677721599 0 MV03—UW
705 2C1 03h, 04h 0 MV03—LW
706 2C2 03h, 04h 15 –1677721599 +1677721599 0 MV04—UW
707 2C3 03h, 04h 0 MV04—LW
708 2C4 03h, 04h 15 –1677721599 +1677721599 0 MV05—UW
709 2C5 03h, 04h 0 MV05—LW
710 2C6 03h, 04h 15 –1677721599 +1677721599 0 MV06—UW
711 2C7 03h, 04h 0 MV06—LW
712 2C8 03h, 04h 15 –1677721599 +1677721599 0 MV07—UW
713 2C9 03h, 04h 0 MV07—LW
714 2CA 03h, 04h 15 –1677721599 +1677721599 0 MV08—UW
715 2CB 03h, 04h 0 MV08—LW
716 2CC 03h, 04h 15 –1677721599 +1677721599 0 MV09—UW
717 2CD 03h, 04h 0 MV09—LW
718 2CE 03h, 04h 15 –1677721599 +1677721599 0 MV10—UW
719 2CF 03h, 04h 0 MV10—LW
720 2D0 03h, 04h 15 –1677721599 +1677721599 0 MV11—UW
721 2D1 03h, 04h 0 MV11—LW
722 2D2 03h, 04h 15 –1677721599 +1677721599 0 MV12—UW
723 2D3 03h, 04h 0 MV12—LW
724 2D4 03h, 04h 15 –1677721599 +1677721599 0 MV13—UW
725 2D5 03h, 04h 0 MV13—LW
726 2D6 03h, 04h 15 –1677721599 +1677721599 0 MV14—UW
727 2D7 03h, 04h 0 MV14—LW
728 2D8 03h, 04h 15 –1677721599 +1677721599 0 MV15—UW
729 2D9 03h, 04h 0 MV15—LW
730 2DA 03h, 04h 15 –1677721599 +1677721599 0 MV16—UW
731 2DB 03h, 04h 0 MV16—LW
732 2DC 03h, 04h 15 –1677721599 +1677721599 0 MV17—UW
733 2DD 03h, 04h 0 MV17—LW
Table E.15 Modbus Register Map (Sheet 12 of 25)
Address in
Decimal
Address
in Hex
Function
Code
Supported
Conversion Min Max Default Name/Enums Units
