E.19
Date Code 20130214 Instruction Manual SEL-2414 Transformer Monitor
Modbus Communications
Modbus Register Map
734 2DE 03h, 04h 15 –1677721599 +1677721599 0 MV18—UW
735 2DF 03h, 04h 0 MV18—LW
736 2E0 03h, 04h 15 –1677721599 +1677721599 0 MV19—UW
737 2E1 03h, 04h 0 MV19—LW
738 2E2 03h, 04h 15 –1677721599 +1677721599 0 MV20—UW
739 2E3 03h, 04h 0 MV20—LW
740 2E4 03h, 04h 15 –1677721599 +1677721599 0 MV21—UW
741 2E5 03h, 04h 0 MV21—LW
742 2E6 03h, 04h 15 –1677721599 +1677721599 0 MV22—UW
743 2E7 03h, 04h 0 MV22—LW
744 2E8 03h, 04h 15 –1677721599 +1677721599 0 MV23—UW
745 2E9 03h, 04h 0 MV23—LW
746 2EA 03h, 04h 15 –1677721599 +1677721599 0 MV24—UW
747 2EB 03h, 04h 0 MV24—LW
748 2EC 03h, 04h 15 –1677721599 +1677721599 0 MV25—UW
749 2ED 03h, 04h 0 MV25—LW
750 2EE 03h, 04h 15 –1677721599 +1677721599 0 MV26—UW
751 2EF 03h, 04h 0 MV26—LW
752 2F0 03h, 04h 15 –1677721599 +1677721599 0 MV27—UW
753 2F1 03h, 04h 0 MV27—LW
754 2F2 03h, 04h 15 –1677721599 +1677721599 0 MV28—UW
755 2F3 03h, 04h 0 MV28—LW
756 2F4 03h, 04h 15 –1677721599 +1677721599 0 MV29—UW
757 2F5 03h, 04h 0 MV29—LW
758 2F6 03h, 04h 15 –1677721599 +1677721599 0 MV30—UW
759 2F7 03h, 04h 0 MV30—LW
760 2F8 03h, 04h 15 –1677721599 +1677721599 0 MV31—UW
761 2F9 03h, 04h 0 MV31—LW
762 2FA 03h, 04h 15 –1677721599 +1677721599 0 MV32—UW
763 2FB 03h, 04h 0 MV32—LW
764–899 2FC–383 03h, 04h 5 8000 8000 8000 Reserved = 8000 Hex
Device Counters
900 384 03h, 04h 1 0 65000 0 SC01 Value
901 385 03h, 04h 1 0 65000 0 SC02 Value
902 386 03h, 04h 1 0 65000 0 SC03 Value
903 387 03h, 04h 1 0 65000 0 SC04 Value
904 388 03h, 04h 1 0 65000 0 SC05 Value
905 389 03h, 04h 1 0 65000 0 SC06 Value
906 38A 03h, 04h 1 0 65000 0 SC07 Value
907 38B 03h, 04h 1 0 65000 0 SC08 Value
Table E.15 Modbus Register Map (Sheet 13 of 25)
Address in
Decimal
Address
in Hex
Function
Code
Supported
Conversion Min Max Default Name/Enums Units
