E.20
SEL-2414 Transformer Monitor Instruction Manual Date Code 20130214
Modbus Communications
Modbus Register Map
908 38C 03h, 04h 1 0 65000 0 SC09 Value
909 38D 03h, 04h 1 0 65000 0 SC10 Value
910 38E 03h, 04h 1 0 65000 0 SC11 Value
911 38F 03h, 04h 1 0 65000 0 SC12 Value
912 390 03h, 04h 1 0 65000 0 SC13 Value
913 391 03h, 04h 1 0 65000 0 SC14 Value
914 392 03h, 04h 1 0 65000 0 SC15 Value
915 393 03h, 04h 1 0 65000 0 SC16 Value
916 394 03h, 04h 1 0 65000 0 SC17 Value
917 395 03h, 04h 1 0 65000 0 SC18 Value
918 396 03h, 04h 1 0 65000 0 SC19 Value
919 397 03h, 04h 1 0 65000 0 SC20 Value
920 398 03h, 04h 1 0 65000 0 SC21 Value
921 399 03h, 04h 1 0 65000 0 SC22 Value
922 39A 03h, 04h 1 0 65000 0 SC23 Value
923 39B 03h, 04h 1 0 65000 0 SC24 Value
924 39C 03h, 04h 1 0 65000 0 SC25 Value
925 39D 03h, 04h 1 0 65000 0 SC26 Value
926 39E 03h, 04h 1 0 65000 0 SC27 Value
927 39F 03h, 04h 1 0 65000 0 SC28 Value
928 3A0 03h, 04h 1 0 65000 0 SC29 Value
929 3A1 03h, 04h 1 0 65000 0 SC30 Value
930 3A2 03h, 04h 1 0 65000 0 SC31 Value
931 3A3 03h, 04h 1 0 65000 0 SC32 Value
932–949 3A4–3B5 03h, 04h 5 8000 8000 8000 Reserved = 8000 Hex
Device Date/Time
950 3B6 03h, 04h,
06h, 10h
3059 ss
951 3B7 03h, 04h,
06h, 10h
1059 mm
952 3B8 03h, 04h,
06h, 10h
1023 HH
953 3B9 03h, 04h,
06h, 10h
1131 DD
954 3BA 03h, 04h,
06h, 10h
1112 MM
955 3BB 03h, 04h,
06h, 10h
1 2000 2999 YY
956–999 3BC–3E7 03h, 04h 5 8000 8000 8000 Reserved = 8000 Hex
Table E.15 Modbus Register Map (Sheet 14 of 25)
Address in
Decimal
Address
in Hex
Function
Code
Supported
Conversion Min Max Default Name/Enums Units
