Sel 2414 - Page 298

E.22
SEL-2414 Transformer Monitor Instruction Manual Date Code 20130214
Modbus Communications
Modbus Register Map
1158 486 03h, 04h 1 0 65535 0 Bad Packet Format
1159 487 03h, 04h 1 0 65535 0 Bad Packet Length
1160–1199 488–4AF 03h, 04h 5 8000 8000 8000 Reserved = 8000 Hex
Remote Analogs
1200–1209 4B0–4B9 03h, 04h,
06h, 10h
15 –9999999 9999999 0 RA001 [0: UW], [1: LW] to
RA005 [0: UW], [1: LW]
1210–1215 4BA–4BF 03h, 04h,
06h, 10h
15 –9999999 9999999 0 RA006 [0: UW], [1: LW] to
RA008 [0: UW], [1: LW]
1216–1225 4C0–4C9 03h, 04h,
06h, 10h
15 –9999999 9999999 0 RA009 [0: UW], [1: LW] to
RA013 [0: UW], [1: LW]
1226–1231 4CA–4CF 03h, 04h,
06h, 10h
15 –9999999 9999999 0 RA014 [0: UW], [1: LW] to
RA016 [0: UW], [1: LW]
1232–1241 4D0–4D9 03h, 04h,
06h, 10h
15 –9999999 9999999 0 RA017 [0: UW], [1: LW] to
RA021 [0: UW], [1: LW]
1242–1247 4DA–4DF 03h, 04h,
06h, 10h
15 –9999999 9999999 0 RA022 [0: UW], [1: LW] to
RA024 [0: UW], [1: LW]
1248–1257 4E0–4E9 03h, 04h,
06h, 10h
15 –9999999 9999999 0 RA025 [0: UW], [1: LW] to
RA029 [0: UW], [1: LW]
1258–1263 4EA–4EF 03h, 04h,
06h, 10h
15 –9999999 9999999 0 RA030 [0: UW], [1: LW] to
RA032 [0: UW], [1: LW]
1264–1273 4F0–4F9 03h, 04h,
06h, 10h
15 –9999999 9999999 0 RA033 [0: UW], [1: LW] to
RA037 [0: UW], [1: LW]
1274–1279 4FA–4FF 03h, 04h,
06h, 10h
15 –9999999 9999999 0 RA038 [0: UW], [1: LW] to
RA040 [0: UW], [1: LW]
1280–1289 500–509 03h, 04h,
06h, 10h
15 –9999999 9999999 0 RA041 [0: UW], [1: LW] to
RA045 [0: UW], [1: LW]
1290–1295 50A–50F 03h, 04h,
06h, 10h
15 –9999999 9999999 0 RA046 [0: UW], [1: LW] to
RA048 [0: UW], [1: LW]
1296–1305 510–519 03h, 04h,
06h, 10h
15 –9999999 9999999 0 RA049 [0: UW], [1: LW] to
RA053 [0: UW], [1: LW]
1306–1311 51A–51F 03h, 04h,
06h, 10h
15 –9999999 9999999 0 RA054 [0: UW], [1: LW] to
RA056 [0: UW], [1: LW]
1312–1321 520–529 03h, 04h,
06h, 10h
15 –9999999 9999999 0 RA057 [0: UW], [1: LW] to
RA061 [0: UW], [1: LW]
1322–1327 52A–52F 03h, 04h,
06h, 10h
15 –9999999 9999999 0 RA062 [0: UW], [1: LW] to
RA064 [0: UW], [1: LW]
1328–1337 530–539 03h, 04h,
06h, 10h
15 –9999999 9999999 0 RA065 [0: UW], [1: LW] to
RA069 [0: UW], [1: LW]
1338–1343 53A–53F 03h, 04h,
06h, 10h
15 –9999999 9999999 0 RA070 [0: UW], [1: LW] to
RA072 [0: UW], [1: LW]
1344–1353 540–549 03h, 04h,
06h, 10h
15 –9999999 9999999 0 RA073 [0: UW], [1: LW] to
RA077 [0: UW], [1: LW]
1354–1359 54A–54F 03h, 04h,
06h, 10h
15 –9999999 9999999 0 RA078 [0: UW], [1: LW] to
RA080 [0: UW], [1: LW]
Table E.15 Modbus Register Map (Sheet 16 of 25)
Address in
Decimal
Address
in Hex
Function
Code
Supported
Conversion Min Max Default Name/Enums Units
