E.23
Date Code 20130214 Instruction Manual SEL-2414 Transformer Monitor
Modbus Communications
Modbus Register Map
1360–1369 550–559 03h, 04h,
06h, 10h
15 –9999999 9999999 0 RA081 [0: UW], [1: LW] to
RA085 [0: UW], [1: LW]
1370–1375 55A–55F 03h, 04h,
06h, 10h
15 –9999999 9999999 0 RA086 [0: UW], [1: LW] to
RA088 [0: UW], [1: LW]
1376–1385 560–569 03h, 04h,
06h, 10h
15 –9999999 9999999 0 RA089 [0: UW], [1: LW] to
RA093 [0: UW], [1: LW]
1386–1391 56A–56F 03h, 04h,
06h, 10h
15 –9999999 9999999 0 RA094 [0: UW], [1: LW] to
RA096 [0: UW], [1: LW]
1392–1401 570–579 03h, 04h,
06h, 10h
15 –9999999 9999999 0 RA097 [0: UW], [1: LW] to
RA101 [0: UW], [1: LW]
1402–1407 57A–57F 03h, 04h,
06h, 10h
15 –9999999 9999999 0 RA102 [0: UW], [1: LW] to
RA104 [0: UW], [1: LW]
1408–1417 580–589 03h, 04h,
06h, 10h
15 –9999999 9999999 0 RA105 [0: UW], [1: LW] to
RA109 [0: UW], [1: LW]
1418–1423 58A–58F 03h, 04h,
06h, 10h
15 –9999999 9999999 0 RA110 [0: UW], [1: LW] to
RA112 [0: UW], [1: LW]
1424–1433 590–599 03h, 04h,
06h, 10h
15 –9999999 9999999 0 RA113 [0: UW], [1: LW] to
RA117 [0: UW], [1: LW]
1434–1439 59A–59F 03h, 04h,
06h, 10h
15 –9999999 9999999 0 RA118 [0: UW], [1: LW] to
RA120 [0: UW], [1: LW]
1440–1449 5A0–5A9 03h, 04h,
06h, 10h
15 –9999999 9999999 0 RA121 [0: UW], [1: LW] to
RA125 [0: UW], [1: LW]
1450–1455 5AA–5AF 03h, 04h,
06h, 10h
15 –9999999 9999999 0 RA126 [0: UW], [1: LW] to
RA128 [0: UW], [1: LW]
1456–1999 5B0–7CF 03h, 04h 5 8000 8000 8000 Reserved = 8000 Hex
Command Region
2000 7D0 03h, 04h,
06h
f
, 10h
11 Parameter 2
g
2001 7D1 03h, 04h,
06h
f
, 10h
11 Parameter 1
g
2002 7D2 03h, 04h,
06h
f
10h
11 Command Code
g
Demand Data
2100 834 03h, 04h 1 0 65535 0 Demand IA A
2101 835 03h, 04h 1 0 65535 0 Demand IB A
2102 836 03h, 04h 1 0 65535 0 Demand IC A
2103 837 03h, 04h 1 0 65535 0 Demand IN A
2104 838 03h, 04h 1 0 65535 0 Demand IG A
2105 839 03h, 04h 1 0 65535 0 Demand 3I2 A
2106 83A 03h, 04h 1 0 65535 0 Demand IAX A
2107 83B 03h, 04h 1 0 65535 0 Demand IBX A
2108 83C 03h, 04h 1 0 65535 0 Demand ICX A
2109 83D 03h, 04h 1 0 65535 0 Demand IGX A
Table E.15 Modbus Register Map (Sheet 17 of 25)
Address in
Decimal
Address
in Hex
Function
Code
Supported
Conversion Min Max Default Name/Enums Units
