SEL-2414 Transformer Monitor Instruction Manual Date Code 20130214
Modbus Communications
Modbus Register Map
2110 83E 03h, 04h 1 0 65535 0 Demand 3I2X A
2111–2149 83F–865 03h, 04h 5 8000 8000 8000 Reserved = 8000 Hex
Peak Demand Data
2150 866 03h, 04h 1 0 65535 0 Peak Demand IA A
2151 867 03h, 04h 1 0 65535 0 Peak Demand IB A
2152 868 03h, 04h 1 0 65535 0 Peak Demand IC A
2153 869 03h, 04h 1 0 65535 0 Peak Demand IN A
2154 86A 03h, 04h 1 0 65535 0 Peak Demand IG A
2155 86B 03h, 04h 1 0 65535 0 Peak Demand 3I2 A
2156 86C 03h, 04h 1 0 65535 0 Peak Demand IAX A
2157 86D 03h, 04h 1 0 65535 0 Peak Demand IBX A
2158 86E 03h, 04h 1 0 65535 0 Peak Demand ICX A
2159 86F 03h, 04h 1 0 65535 0 Peak Demand IGX A
2160 870 03h, 04h 1 0 65535 0 Peak Demand 3I2X A
2161–2199 871–897 03h, 04h 5 8000 8000 8000 Reserved = 8000 Hex
Min/Max Data
c
2200 898 03h, 04h 1 0 65535 0 IA MAX A
2201 899 03h, 04h 1 0 65535 0 IA MIN A
2202 89A 03h, 04h 1 0 65535 0 IB MAX A
2203 89B 03h, 04h 1 0 65535 0 IB MIN A
2204 89C 03h, 04h 1 0 65535 0 IC MAX A
2205 89D 03h, 04h 1 0 65535 0 IC MIN A
2206 89E 03h, 04h 1 0 65535 0 IN MAX A
2207 89F 03h, 04h 1 0 65535 0 IN MIN A
2208 8A0 03h, 04h 1 0 65535 0 IG MAX A
2209 8A1 03h, 04h 1 0 65535 0 IG MIN A
2210 8A2 03h, 04h 1 0 65535 0 3I2 MAX A
2211 8A3 03h, 04h 1 0 65535 0 3I2 MIN A
2212 8A4 03h, 04h 1 0 65535 0 IAX MAX A
2213 8A5 03h, 04h 1 0 65535 0 IAX MIN A
2214 8A6 03h, 04h 1 0 65535 0 IBX MAX A
2215 8A7 03h, 04h 1 0 65535 0 IBX MIN A
2216 8A8 03h, 04h 1 0 65535 0 ICX MAX A
2217 8A9 03h, 04h 1 0 65535 0 ICX MIN A
2218 8AA 03h, 04h 1 0 65535 0 IGX MAX A
2219 8AB 03h, 04h 1 0 65535 0 IGX MIN A
2220 8AC 03h, 04h 1 0 65535 0 3I2X MAX A
2221 8AD 03h, 04h 1 0 65535 0 3I2X MIN A
2222 8AE 03h, 04h 13 0 5200000 0 VAB MAX—UW V
2223 8AF 03h, 04h 0 0 VAB MAX—LW V
Table E.15 Modbus Register Map (Sheet 18 of 25)
Address in
Decimal
Address
in Hex
Function
Code
Supported
Conversion Min Max Default Name/Enums Units
