E.25
Date Code 20130214 Instruction Manual SEL-2414 Transformer Monitor
Modbus Communications
Modbus Register Map
2224 8B0 03h, 04h 13 0 5200000 0 VAB MIN—UW V
2225 8B1 03h, 04h 0 0 VAB MIN—LW V
2226 8B2 03h, 04h 13 0 5200000 0 VBC MAX—UW V
2227 8B3 03h, 04h 0 0 VBC MAX—LW V
2228 8B4 03h, 04h 13 0 5200000 0 VBC MIN—UW V
2229 8B5 03h, 04h 0 0 VBC MIN—LW V
2230 8B6 03h, 04h 13 0 5200000 0 VCA MAX—UW V
2231 8B7 03h, 04h 0 0 VCA MAX—LW V
2232 8B8 03h, 04h 13 0 5200000 0 VCA MIN—UW V
2233 8B9 03h, 04h 0 0 VCA MIN—LW V
2234 8BA 03h, 04h 13 0 5200000 0 VA MAX—UW V
2235 8BB 03h, 04h 0 0 VA MAX—LW V
2236 8BC 03h, 04h 13 0 5200000 0 VA MIN—UW V
2237 8BD 03h, 04h 0 0 VA MIN—LW V
2238 8BE 03h, 04h 13 0 5200000 0 VB MAX—UW V
2239 8BF 03h, 04h 0 0 VB MAX—LW V
2240 8C0 03h, 04h 13 0 5200000 0 VB MIN—UW V
2241 8C1 03h, 04h 0 0 VB MIN—LW V
2242 8C2 03h, 04h 13 0 5200000 0 VC MAX—UW V
2243 8C3 03h, 04h 0 0 VC MAX—LW V
2244 8C4 03h, 04h 13 0 5200000 0 VC MIN—UW V
2245 8C5 03h, 04h 0 0 VC MIN—LW V
2246 8C6 03h, 04h 13 –200000000 200000000 0 3-Phase Real Power
MAX—UW
kW
2247 8C7 03h, 04h 0 0 3-Phase Real Power
MAX—LW
kW
2248 8C8 03h, 04h 13 –200000000 200000000 0 3-Phase Real Power MIN—
UW
kW
2249 8C9 03h, 04h 0 0 3-Phase Real Power MIN—
LW
kW
2250 8CA 03h, 04h 13 –200000000 200000000 0 3-Phase Reactive Power
MAX—UW
kVAR
2251 8CB 03h, 04h 0 0 3-Phase Reactive Power
MAX—LW
kVAR
2252 8CC 03h, 04h 13 –200000000 200000000 0 3-Phase Reactive Power
MIN—UW
kVAR
2253 8CD 03h, 04h 0 0 3-Phase Reactive Power
MIN—LW
kVAR
2254 8CE 03h, 04h 13 –200000000 200000000 0 3-Phase Apparent Power
MAX—UW
kVA
2255 8CF 03h, 04h 0 0 3-Phase Apparent Power
MAX—LW
kVA
2256 8D0 03h, 04h 13 –200000000 200000000 0 3-Phase Apparent Power
MIN—UW
kVA
Table E.15 Modbus Register Map (Sheet 19 of 25)
Address in
Decimal
Address
in Hex
Function
Code
Supported
Conversion Min Max Default Name/Enums Units
