Sel 2414 - Page 302

E.26
SEL-2414 Transformer Monitor Instruction Manual Date Code 20130214
Modbus Communications
Modbus Register Map
2257 8D1 03h, 04h 0 0 3-Phase Apparent Power
MIN—LW
kVA
2258 8D2 03h, 04h 13 –200000000 200000000 0 3-Phase Real Power X
MAX—UW
kW
2259 8D3 03h, 04h 0 0 3-Phase Real Power X
MAX—LW
kW
2260 8D4 03h, 04h 13 –200000000 200000000 0 3-Phase Real Power X
MIN—UW
kW
2261 8D5 03h, 04h 0 0 3-Phase Real Power X
MIN—LW
kW
2262 8D6 03h, 04h 13 –200000000 200000000 0 3-Phase Reactive Power X
MAX—UW
kVAR
2263 8D7 03h, 04h 0 0 3-Phase Reactive Power X
MAX—LW
kVAR
2264 8D8 03h, 04h 13 –200000000 200000000 0 3-Phase Reactive Power X
MIN—UW
kVAR
2265 8D9 03h, 04h 0 0 3-Phase Reactive Power X
MIN—LW
kVAR
2266 8DA 03h, 04h 13 –200000000 200000000 0 3-Phase Apparent Power X
MAX—UW
kVA
2267 8DB 03h, 04h 0 0 3-Phase Apparent Power X
MAX—LW
kVA
2268 8DC 03h, 04h 13 –200000000 200000000 0 3-Phase Apparent Power X
MIN—UW
kVA
2269 8DD 03h, 04h 0 0 3-Phase Apparent Power X
MIN—LW
kVA
2270 8DE 03h, 04h 1 440 660 0 Frequency MAX Hz
2271 8DF 03h, 04h 1 440 660 0 Frequency MIN Hz
2272–2499 8E0–9C3 03h, 04h 5 8000 8000 8000 Reserved = 8000 Hex
Energy Data
c
2500 9C4 03h, 04h 13 0 1000000 0 Real Energy 3-Phase Real
Power In—UW
MWh
2501 9C5 03h, 04h Real Energy 3-Phase Real
Power In—LW
MWh
2502 9C6 03h, 04h 13 0 1000000 0 Real Energy 3-Phase Real
Power Out—UW
MWh
2503 9C7 03h, 04h Real Energy 3-Phase Real
Power Out—LW
MWh
2504 9C8 03h, 04h 13 0 1000000 0 Reactive Energy 3-Phase
Reactive Power In—UW
MVARh
2505 9C9 03h, 04h Reactive Energy 3-Phase
Reactive Power In—LW
MVARh
2506 9CA 03h, 04h 13 0 1000000 0 Reactive Energy 3-Phase
Reactive Power Out—UW
MVARh
2507 9CB 03h, 04h Reactive Energy 3-Phase
Reactive Power Out—LW
MVARh
Table E.15 Modbus Register Map (Sheet 20 of 25)
Address in
Decimal
Address
in Hex
Function
Code
Supported
Conversion Min Max Default Name/Enums Units
