Sel 2414 - Page 303

E.27
Date Code 20130214 Instruction Manual SEL-2414 Transformer Monitor
Modbus Communications
Modbus Register Map
2508 9CC 03h, 04h 13 0 1000000 0 Real Energy 3-Phase Real
Power X In—UW
MWh
2509 9CD 03h, 04h Real Energy 3-Phase Real
Power X In—LW
MWh
2510 9CE 03h, 04h 13 0 1000000 0 Real Energy 3-Phase Real
Power X Out—UW
MWh
2511 9CF 03h, 04h Real Energy 3-Phase Real
Power X Out—LW
MWh
2512 9D0 03h, 04h 13 0 1000000 0 Reactive Energy 3-Phase
Reactive Power X In—UW
MVARh
2513 9D1 03h, 04h Reactive Energy 3-Phase
Reactive Power X In—LW
MVARh
2514 9D2 03h, 04h 13 0 1000000 0 Reactive Energy 3-Phase
Reactive Power X Out—
UW
MVARh
2515 9D3 03h, 04h Reactive Energy 3-Phase
Reactive Power X Out—
LW
MVARh
2516–2599 9D4–A27 03h, 04h 5 8000 8000 8000 Reserved = 8000 Hex
Thermal Data
2600 A28 03h, 04h 3 0 10000 0 Percentage of full load
(Transformer 1)
%
2601 A29 03h, 04h 3 0 10000 0 Percentage of full load
(Transformer 2)
%
2602 A2A 03h, 04h 3 0 10000 0 Percentage of full load
(Transformer 3)
%
2603 A2B 03h, 04h 6 –32768 32767 0 Calculated transformer top
oil temperature
(Transformer 1)
°C
2604 A2C 03h, 04h 6 –32768 32767 0 Calculated transformer top
oil temperature
(Transformer 2)
°C
2605 A2D 03h, 04h 6 –32768 32767 0 Calculated transformer top
oil temperature
(Transformer 3)
°C
2606 A2E 03h, 04h 6 –32768 32767 0 Measured ambient
temperature
°C
2607 A2F 03h, 04h 6 –32768 32767 0 Measured top oil
temperature (Transformer 1)
°C
2608 A30 03h, 04h 6 –32768 32767 0 Measured top oil
temperature (Transformer 2)
°C
2609 A31 03h, 04h 6 –32768 32767 0 Measured top oil
temperature (Transformer 3)
°C
2610 A32 03h, 04h 6 –32768 32767 0 Calculated Hot spot
temperature (Transformer 1)
°C
2611 A33 03h, 04h 6 –32768 32767 0 Calculated Hot spot
temperature (Transformer 2)
°C
2612 A34 03h, 04h 6 –32768 32767 0 Calculated Hot spot
temperature (Transformer 3)
°C
Table E.15 Modbus Register Map (Sheet 21 of 25)
Address in
Decimal
Address
in Hex
Function
Code
Supported
Conversion Min Max Default Name/Enums Units
