SEL-2414 Transformer Monitor Instruction Manual Date Code 20130214
Modbus Communications
Modbus Register Map
2613 A35 03h, 04h 1 0 8 0 Thermal Element Condition
(Transformer 1)
2614 A36 03h, 04h 1 0 8 0 Thermal Element Condition
(Transformer 2)
2615 A37 03h, 04h 1 0 8 0 Thermal Element Condition
(Transformer 3)
2616 A38 03h, 04h 15 0 999900 0 Insulation Aging
Acceleration Factor
(Transformer 1)—UW
2617 A39 03h, 04h Insulation Aging
Acceleration Factor
(Transformer 1)—LW
2618 A3A 03h, 04h 15 0 999900 0 Insulation Aging
Acceleration Factor
(Transformer 2)—UW
2619 A3B 03h, 04h Insulation Aging
Acceleration Factor
(Transformer 2)—LW
2620 A3C 03h, 04h 15 0 999900 0 Insulation Aging
Acceleration Factor
(Transformer 3)—UW
2621 A3D 03h, 04h Insulation Aging
Acceleration Factor
(Transformer 3)—LW
2622 A3E 03h, 04h 16 0 100000 0 Rate of Loss-of-Life
(Transformer 1)—UW
%
2623 A3F 03h, 04h Rate of Loss-of-Life
(Transformer 1)—LW
2624 A40 03h, 04h 16 0 100000 0 Rate of Loss-of-Life
(Transformer 2)—UW
%
2625 A41 03h, 04h Rate of Loss-of-Life
(Transformer 2)—LW
2626 A42 03h, 04h 16 0 100000 0 Rate of Loss-of-Life
(Transformer 3)—UW
%
2627 A43 03h, 04h Rate of Loss-of-Life
(Transformer 3)—LW
2628 A44 03h, 04h 16 0 100000 0 Total Loss-of-Life
(Transformer 1)—UW
%
2629 A45 03h, 04h Total Loss-of-Life
(Transformer 1)—LW
2630 A46 03h, 04h 16 0 100000 0 Total Loss-of-Life
(Transformer 2)—UW
%
2631 A47 03h, 04h Total Loss-of-Life
(Transformer 2)—LW
2632 A48 03h, 04h 16 0 100000 0 Total Loss-of-Life
(Transformer 3)—UW
%
2633 A49 03h, 04h Total Loss-of-Life
(Transformer 3)—LW
Table E.15 Modbus Register Map (Sheet 22 of 25)
Address in
Decimal
Address
in Hex
Function
Code
Supported
Conversion Min Max Default Name/Enums Units
