F.14 IEC 61850 Communications
ACSI Conformance Statements
SEL-2414 Transformer Monitor Instruction Manual Date Code 20130214
M7-4 data-set-name YES
M7-5 data-reference YES
M7-6 buffer-overflow YES
M7-7 entryID YES
M7-8 BufTm YES
M7-9 IntgPd YES
M7-10 G1 YES
M8 Unbuffered report control O
e
O
e
YES
M8-1 sequence-number YES
M8-2 report-time-stamp YES
M8-3 reason-for-inclusion YES
M8-4 data-set-name YES
M8-5 data-reference YES
M8-6 BufTm YES
M8-7 IntgPd YES
M-8-8 GI YES
Logging
O
e
O
e
M9 Log control O
e
O
e
M9-1 IntgPd
M10 Log O
e
O
e
M11 Control M
f
M
f
YES
If GSE (B31/32) Is Supported
M12 GOOSE O
e
O
e
YES
M12-1 entryID YES
M12-2 DataReflnc YES
M13 GSSE O
e
O
e
If GSE (B41/42) Is Supported
M14 Multicast SVC O
e
O
e
M15 Unicast SVC O
e
O
e
M16 Time M
f
M
f
M17 File Transfer O
e
O
e
a
c2 shall be “M” if support for LOGICAL-NODE model has been declared.
b
c3 shall be “M” if support for DATA model has been declared.
c
c4 shall be “M” if support for DATA-SET, Substitution, Report, Log Control, or Time model has been declared.
d
c5 shall be “M” if support for Report, GSE, or SV models has been declared.
e
O = Optional.
f
M = Mandatory.
Table F.20 ACSI Models Conformance Statement (Sheet 2 of 2)
Client/Subscriber Server/Publisher SEL-2414 Support
