Date Code 20130214 Instruction Manual SEL-2414 Transformer Monitor
Device Word Bits
Definitions
91 * Reserved—Pad Byte
* Reserved
92 IN101E Edge detect digital input slot 1 input 101
IN102E Edge detect digital input slot 1 input 102
* Reserved
93 IN301E–IN308E Edge detect digital inputs slot 3
94 IN401E–IN408E Edge detect digital inputs slot 4
95 IN501E–IN508E Edge detect digital inputs slot 5
96 IN601E–IN608E Edge detect digital inputs slot 6
97 RMB8A–RMB1A Channel A receive M
IRRORED BITS
®
RMB1A–RMB8A
98 TMB8A–TMB1A Channel A transmit M
IRRORED BITS TMB1A–TMB8A
99 RMB8B–RMB1B Channel B receive M
IRRORED BITS RMB1B–RMB8B
100 TMB8B–TMB1B Channel B transmit M
IRRORED BITS TMB1B–TMB8B
101 LBOKB Channel B, looped back ok
CBADB Channel B, channel unavailability over threshold
RBADB Channel B, outage duration over threshold
ROKB Channel B, received data ok
LBOKA Channel A, looped back ok
CBADA Channel A, channel unavailability over threshold
RBADA Channel A, outage duration over threshold
ROKA Channel A, received data ok
102 PB01–PB04 Front-panel pushbutton 1–4 bit
* Reserved
103 PB01_PUL–
PB04_PUL
Front-panel pushbutton 1–4 pulse bit (asserted for one processing interval when PB01–PB04 is pressed)
* Reserved
104 VB001–VB008 Virtual Bits used for Incoming GOOSE messages
105 VB009–VB016 Virtual Bits used for Incoming GOOSE messages
106 VB017–VB024 Virtual Bits used for Incoming GOOSE messages
107 VB025–VB032 Virtual Bits used for Incoming GOOSE messages
108 VB033–VB040 Virtual Bits used for Incoming GOOSE messages
109 VB041–VB048 Virtual Bits used for Incoming GOOSE messages
110 VB049–VB056 Virtual Bits used for Incoming GOOSE messages
111 VB057–VB064 Virtual Bits used for Incoming GOOSE messages
112 VB065–VB072 Virtual Bits used for Incoming GOOSE messages
113 VB073–VB080 Virtual Bits used for Incoming GOOSE messages
114 VB081–VB088 Virtual Bits used for Incoming GOOSE messages
115 VB089–VB096 Virtual Bits used for Incoming GOOSE messages
116 VB097–VB104 Virtual Bits used for Incoming GOOSE messages
117 VB105–VB112 Virtual Bits used for Incoming GOOSE messages
118 VB113–VB120 Virtual Bits used for Incoming GOOSE messages
119 VB121–VB128 Virtual Bits used for Incoming GOOSE messages
120 PB01BLED–
PB04BLED
*
SEL
OGIC Equation: Drives Lower Pushbutton LEDs
Reserved
Table H.2 Device Word Bit Definitions (Sheet 4 of 7)
