SEL-2414 Transformer Monitor Instruction Manual Date Code 20130214
Device Word Bits
Definitions
135 T1_RLL
a
Transformer 1 rate of loss of life alarm. Replace with RLL_1.
W1_RLL
b
Winding 1 rate of loss of life alarm
W2_RLL
b
Winding 2 rate of loss of life alarm
W3_RLL
b
Winding 3 rate of loss of life alarm
T1_TLL
a
Transformer 1 total of loss of life alarm. Replace with TLL_1.
W1_TLL
b
Winding 1 total of loss of life alarm
W2_TLL
b
Winding 2 total of loss of life alarm
W3_TLL
b
Winding 3 total of loss of life alarm
136 T1_CSCM
a
Transformer 1 cooling coefficient or measurement alarm. Replace with CSCM_1.
W1_CSCM
a
Winding 1 cooling coefficient or measurement alarm. Replace with CSCM_1.
W2_CSCM
a
Winding 2 cooling coefficient or measurement alarm. Replace with CSCM_2.
W3_CSCM
a
Winding 3 cooling coefficient or measurement alarm. Replace with CSCM_3.
T1_CSE
a
Transformer 1 cooling stage efficiency alarm. Replace with CSE_1.
W1_CSE
a
Winding 1 cooling stage efficiency alarm. Replace with CSE_1.
W2_CSE
a
Winding 2 cooling stage efficiency alarm. Replace with CSE_2.
W3_CSE
a
Winding 3 cooling stage efficiency alarm. Replace with CSE_3.
137 W1_LVL1
b
Winding 1 thermal element warning level 1
W1_LVL2
b
Winding 1 thermal element warning level 2
W1_LVL3
b
Winding 1 thermal element warning level 3
* Reserved
W2_LVL1
b
Winding 2 thermal element warning level 1
W2_LVL2
b
Winding 2 thermal element warning level 2
W2_LVL3
b
Winding 2 thermal element warning level 3
* Reserved
138 W3_LVL1
b
Winding 3 thermal element warning level 1
W3_LVL2
b
Winding 3 thermal element warning level 2
W3_LVL3
b
Winding 3 thermal element warning level 3
* Reserved
* Reserved
* Reserved
* Reserved
* Reserved
a
Do not use for new settings. Obsolete.
b
Valid when ETHERM = W.
Table H.2 Device Word Bit Definitions (Sheet 7 of 7)
Row Bit Definition
