I.2
SEL-2414 Transformer Monitor Instruction Manual Date Code 20130214
Analog Quantities
T1TLL–T3TLL Time to Total Loss-of-Life Alarm (hrs) (Transformers 1–3)
W1TLL–W3TLL Time to Total Loss-of-Life Alarm (hrs) (Windings 1–3) always equal
T1TLL–T3TLL
TEC1–TEC3 Thermal Element Condition (Transformers 1–3)
TECW1–TECW3 Thermal Element Condition (Windings 1–3)
e
Date/Time Quantities
YEAR Year number (0000–9999)
DAYY Day of Year number (1–366)
WEEK Week number (1–52)
DAYW Day of Week number (1–7, Sunday is day #1)
MINSM Minutes since Midnight
HOUR Hour (0–23)
MIN Minute (0–59)
SEC Second (0–59)
Instantaneous (Fundamental) Metering Quantities
Ix_MAG Current Magnitude (x = A, B, C, N, and G)
f
Ix_ANG Current Angle (x = A, B, C, N, and G)
f
3I2 Current, negative-sequence, magnitude
f
IxX_MAG Current X Magnitude (x = A, B, C, and G)
g
IxX_ANG Current X Angle (x = A, B, C, and G)
g
3I2X Current X, negative-sequence, magnitude
g,
h
Vx_MAG Voltage Magnitude (x = A, B, C, and G)
g,
i
Vx_ANG Voltage Angle (x = A, B, C, and G)
g,
i
Vxx_MAG Voltage Magnitude (x = AB, BC, and CA)
g,
i
Vxx_ANG Voltage Angle (x = AB, BC, and CA)
g,
i
3V2 Voltage, negative-sequence, magnitude
g,
i
Px Real power magnitude (x = A, B, and C)
h, j
Qx Reactive power magnitude (x = A, B, and C)
h, j
Sx Apparent power magnitude (x = A, B, and C)
h, j
PFx Power factor, magnitude(x = A, B, and C)
j, k
P Real power magnitude, 3-phase
h, j
Q Reactive power magnitude, 3-phase
h, j
S Apparent power magnitude, 3-phase
h, j
PF Power factor, magnitude, 3-phase
h, j
PxX Real power X, magnitude (x = A, B, and C)
g, h
QxX Reactive power X, magnitude (x = A, B, and C)
g, h
SxX Apparent power X, magnitude (x = A, B, and C)
g, h
PFxX Power factor X, magnitude (x = A, B, and C)
g, h
PX Real power X, magnitude, 3-phase
g, h
QX Reactive power X, magnitude, 3-phase
g, h
SX Apparent power X, magnitude, 3-phase
g, h
PFX Power factor X, magnitude, 3-phase
g, k
FREQ Frequency
f,
g
Demand Metering Quantities
IxD Current Demand (x = A, B, C, N, and G)
f
3I2D Negative-Sequence Current Demand
f, h
IxPD Current Peak Demand (x = A, B, C, N, and G)
f
3I2PD Negative-Sequence Current Peak Demand
f, h
IxXD Current X Demand (x = A, B, C, and G)
g
Table I.1 Available Analog Quantities (Sheet 2 of 3)
Analog Quantity Description Note
