I.3
Date Code 20130214 Instruction Manual SEL-2414 Transformer Monitor
Analog Quantities
3I2XD Negative-Sequence Current X Demand
g, h
IxXPD Current Peak X Demand (x = A, B, C, and G)
g
3I2XPD Negative-Sequence Current Peak X Demand
g, h
Maximum/Minimum Metering Quantities
IxMX Current, maximum magnitude (x = A, B, C, N, and G)
f
3I2MX Current, negative sequence, maximum magnitude
f, h
IxXMX Current, maximum magnitude (x = A, B, C, and G)
g
3I2XMX Current, negative sequence, maximum magnitude
g, h
IxMN Current, minimum magnitude (x = A, B, C, N, and G)
f
3I2MN Current, negative sequence, minimum magnitude
f, h
IxXMN Current, minimum magnitude (x = A, B, C, and G)
g
3I2XMN Current, negative sequence, minimum magnitude
g, h
VxxMX Voltage, maximum magnitude (xx = AB, BC, and CA)
g, i
VxMX Voltage, maximum magnitude (x = A, B, and C)
g, i
VxxMN Voltage, minimum magnitude (xx = AB, BC, and CA)
g, i
VxMN Voltage, minimum magnitude (x = A, B, and C)
g, i
Kx3PMX Power magnitude, 3-phase, maximum (x = S, W, and Q)
j, h
Kx3PMN Power magnitude, 3-phase, minimum (x = S, W, and Q)
j, h
Kx3PXMX Power magnitude, 3-phase, maximum (x = S, W, and Q)
g, h
Kx3PXMN Power magnitude, 3-phase, minimum (x = S, W, and Q)
g, h
FREQMX Maximum frequency
f, g
FREQMN Minimum frequency
f, g
Energy Metering Quantities
MWHI Real energy, 3-phase IN
h, j
MWHO Real energy, 3-phase OUT
h, j
MVARHI Reactive energy, 3-phase IN
h, j
MVARHO Reactive energy, 3-phase OUT
h, j
MWHXI Real energy X, 3-phase IN
g, h
MWHXO Real energy X, 3-phase OUT
g, h
MVARHXI Reactive energy X, 3-phase IN
g, h
MVARHXO Reactive energy X, 3-phase OUT
g, h
a
Valid data only if 10 RTD card is installed in Slot D.
b
Valid data only if SEL-2600 Device is connected via fiber port.
c
Valid data only if internal general purpose 10 RTD/TC card is installed in Slot D.
d
Used when ETHERM = 3.
e
Used when ETHERM = W.
f
Valid data only if 4 CT card (4ACI) is installed in Slot Z.
g
Valid data only if 3 CT/3 PT card (3ACI/3AVI) is installed in Slot E.
h
Forced to 0 if ETHERM = W.
i
Valid data only if 3 PT card (3AVI) in installed in Slot E.
j
Valid data only if 4 CT and 3 PT cards (4ACI and 3AVI) are installed in Slots Z and E respectively.
k
Forced to 1.0 if ETHE RM = W.
Table I.1 Available Analog Quantities (Sheet 3 of 3)
Analog Quantity Description Note
