Card Configuration
AUTO setting = N. To interchange cards, perform the following steps:
Step 1. De-energize the device.
Step 2. Remove the eight rear-panel screws, ground screw, plug-in
connectors, and the rear panel.
Step 3. Remove the card from the device.
Step 4. Insert the new card into the slot.
Step 5. Replace the rear panel, reinstall all screws and connectors, and
energize the unit.
Step 6. For an AUTO = Y (Port settings), the device displays the
following:
Step 7. Type Y <Enter> to accept the new configuration. The device
reboots (approximately five seconds) and is ready for service.
For an AUTO = N (Port settings) the device communications
software returns to the Level 0 prompt. The only indication that
the device is disabled is on the front panel, where the ENABLED
LED is not illuminated and the device displays the following
message on the front panel (X indicates the specific slot):
Step 8. Go to Level 1 and type STA <Enter>, followed by Y <Enter> at
the prompt (see Step 6) to accept the new configuration. The
device reboots (approximately five seconds) and is ready for
service.
After reconfiguration, the device updates the part number, except for the digits
shown in Figure 2.3. The digits indicated in Figure 2.3 remain unchanged, i.e.,
these digits retain the same character as before the reconfiguration.
=>STA <Enter>
SEL-2414 Date: 1/29/2002 Time: 17:18:55
DEVICE
Serial Num = 2007036022 FID = SEL-2414-R202-V0-Z003003-D20080429
CID = 0100 PART NUM = 241421AA09X746X1140
SELF TESTS (W=Warn)
FPGA GPSB HMI RAM ROM CR_RAM NON_VOL CLOCK INTRTD CID_FILE +3.3V
OK OK OK OK OK OK OK OK OK OK 3.28
+5.0V +2.5V +3.75V -1.25V -5.0V BATT
4.99 2.48 3.77 -1.27 -4.97 3.37
Option Cards
CARD_C CARD_D CARD_E CARD_Z
OK OK OK OK
Offsets
IA IB IC IN VA VB VC IAX IBX ICX
OK OK OK OK OK OK OK OK OK OK
Device Disabled
Confirm Hardware Config
Accept & Reboot (Y,N)?
STATUS FAIL
Card X Failure
To Next Page
Loading...
