7-12 Routine maintenance

9. Hold the probe handle and open the source lock vent valve (on the left

side of the source lock) by turning counterclockwise, to vent the lock

volume.

10. Release the source lock latch, by turning it counterclockwise.

Source lock

vent valve

Source lock

Source lock latch
