Source maintenance 7-31

4. Fit a ceramic spacer, with the stepped portion uppermost, over each of

the locating dowels.

5. Fit the bayonet support to the ceramic spacers.

Caution: You must fit the bayonet support so that the connector slit is

parallel to the repeller contact.

Connector slit

Repeller contact
