7-48 Routine maintenance
2. Carefully remove the end plate from the outer source assembly.
To remove the inner source contact support assembly
1. Remove the wavy washers from the ceramic rods.
Tip: The number of wavy washers fitted to the ceramic rods varies from
source to source. Note this number, because you must replace these
exactly when reassembling the outer source assembly.
Ceramic rod
Wavy washers
10-mm ceramic spacer
