Component hardware troubleshooting 8-3
The instrument is not in Operate
mode.
In the MassLynx Tune window, click
Press for Operate.
Tip: When in Operate mode, the
adjacent icon is green.
Communication failure. Ascertain the status of the
embedded PC. If necessary, reboot
the embedded PC using the
embedded PC’s power switch.
See “Viewing the status of, and
rebooting, the instrument’s
embedded PC” on page D-28.
No sample is present. Ensure that you loaded the sample
correctly in the autosampler or
probe.
The analyzer isolation valve is
closed.
In the MassLynx Tune window on
the Vacuum tab, select Analyser.
Magnet is off. (Inspect the Tune
window Control 1 page Field Setting
pane Magnet Mass readback.)
In the Instrument Setup dialog box,
select Magnet.
Ensure that the Magnet MCBs are
switched on.
See “A.C. distribution panel” on
page 1-6.
Damaged source filament or poor
contact to the filament from the
spring contacts on the outer source.
[Inspect the Tune window Source
page Source Parameters pane
Filament (A) readback].
Remove the inner source and test
the continuity of the filament with a
digital voltmeter (the resistance
must be approximately 0.2 ohm).
Replace the filament if it is
damaged. If the filament is intact,
use tweezers to adjust the spring
contacts on the outer source to
improve contact.
See “To remove the filament
assembly” on page 7-16 and “To fit
the filament” on page 7-29.
No peaks in the Tune window (no ion beam) (Continued)
Possible cause Corrective action
