SIR function editors 3-31

MRM function editor

MRM function editor parameters :

Parameter Description

AutoSpec Parameter

File pane

Enter the required parameter file name and path in

the text box, or click Browse.

Use Probe Ramping

Method

When selected, you can specify a probe ramping

method (.prf) file name and path in the text box, or

click Browse.
