Phaser 6000/6010 and WC 6015 MFP Xerox Internal Use Only 3-81
Error Messages and Codes
4 Enter diagnostic mode and run the
Regi Sensor test (see page 4-11).
You can also use CE Diag Tool to
perform this test (see page A-9).
Lift the Main Paper Tray Chute
(PL3.3.3), does the number on the
display change each time the Main
Paper Tray Chute is lifted?
Go to step 6. Go to step 5.
5 Disconnect the MCU Board P/J21
and the Registration Sensor P/J120.
Check the Harness Assembly RKN
SNS for continuity.
Is the harness damaged?
Go to step 6. Repair the
harness.
6 Disconnect the MCU Board P/J12.
Is the voltage across ground and
P/J12-1 +3.3VDC?
Replace the
Registration
Sensor
(page 8-65).
Replace the
MCU Board
(page 8-121).
7 Check the connections at MCU
Board P/J16 and at the Main Drive
Assembly P/J60.
Are the connections secure?
Go to step 9. Reconnect the
connectors
and then go to
step 8.
8 Does the error persist? Go to step 9. Complete.
9 Enter diagnostic mode and run
Main Motor on Full (see page 4-11).
You can also use the CE Diag Tool to
run this test (see page A-16).
Does the Main Drive Assembly
function correctly?
Go to step 14. Go to step 10.
10 Is the Main Drive Assembly installed
correctly?
Go to step 12. Reseat the
Main Drive
Assembly, then
go to step 11.
11 Does the error persist? Go to step 12. Complete.
12 Disconnect P/J16 from the MCU
Board and P/J160 from the Main
Drive Assembly.
Check the continuity of the cable.
Is the cable damaged?
Repair the
cable.
Go to step 13.
13 Disconnect the MCU Board P/J16
and check that the voltages across
ground at P/J16-2 and P/J16-4 are
+24 VDC.
Are the voltages correct?
Replace the
Main Drive
Assembly
(page 8-82).
Replace the
MCU Board
(page 8-121).
14 Check the connector of P/J19 on the
MCU Board.
Is the connection secure?
Go to step 16. Reconnect the
connector,
then go to
step 15.
Troubleshooting Procedure Table
Step Actions and Questions Yes No
To Next Page
