Xerox PHASER 6010 Service Manual

3-82 Xerox Internal Use Only Phaser 6000/6010 and WC 6015 MFP
Error Messages and Codes
15 Does the error still occur when
printing?
Go to step 16. Complete.
16 Enter diagnostic mode and run the
Feed SOLENOID test.
You can also use the CE Diag Tool to
run this test (see page A-16).
Does the Feed Solenoid function
correctly?
Go to step 17. Replace the
Feed Solenoid
(page 8-98).
17 Check the connection at MCU Board
P/J25.
Is the connection secure?
Go to step 19. Reconnect the
connector and
then go to
step 18.
18 Does the error still occur when
printing?
Go to step 19. Complete.
19 Enter diagnostic mode and select
Engine Diag > Motor Test > Regi
Clutch.
You can also use the CE Diag Tool to
run this test (see page A-16).
Does the Registration Clutch
function correctly?
Replace the
MCU Board
(page 8-121).
Replace the
Registration
Clutch
(page 8-66).
Troubleshooting Procedure Table
Step Actions and Questions Yes No

Xerox PHASER 6010 Specifications

General

Print Technology	Laser
Print Speed	Up to 12 ppm color / 15 ppm black
Print Resolution	1200 x 2400 dpi
Monthly Duty Cycle	Up to 30, 000 pages
Standard Paper Capacity	150 sheets
Memory	128 MB
Paper Output Capacity	100 sheets
Duplex Printing	Manual
Maximum Paper Capacity	150 sheets
Supported Operating Systems	Windows, Mac OS, Linux
Connectivity	USB 2.0
Weight	24.3 lbs
