Xerox PHASER 6010 Service Manual

Phaser 6000/6010 and WC 6015 MFP Xerox Internal Use Only 4-17
Troubleshooting
Copy Counter MtoB ■ OK?
■ Processing
■ Copied
Copies the values from Master NVM
to Backup NVM on the IP Board.
■ Device-specific information called
“Personal info” in the first 128 Byte
■ PV counter master
■ Printer counter master
Copy Counter BtoM
■ OK?
■ Processing
■ Copied
Copies the values from Backup NVM
to Master NVM on the IP Board.
■ Device-specific information called
“Personal info” in the first 128 Bytes
■ PV counter backup
■ Printer counter backup
Clear All NVM
■ OK?
■ Processing
■ Initialized
Clears all NVM.
Clear Job History
■ OK?
■ Processing
■ Initialized
Deletes job history data from NVM.
Test Print Test prints for troubleshooting the printer.
The available test prints are found in the Test Print menu. For a description of these
test pages, see “Test Prints” on page 5-38.
Parameter Reads/writes the parameter values, errors, and life counter
values stored in the printer.
NOTE Print the parameter list using the Print function found in the Parameter
Menu before changing the value of the registration.
Regi Value
X Margin Y, M, C, K ■ -137 to 137 Adjusts registration in the feed
direction.
Y Margin Y, M, C, K
■ -3780 to 3780 Adjusts registration in the scan
direction.
Skew Y, M, C, K
■ -630 to 630 Adjusts the skew so that the image is
parallel with both sides of the paper.
See the following illustration for additional explanation.
Test LCD (Phaser 6010N) Test D es cr ipti o n

Xerox PHASER 6010 Specifications

General

Print Technology	Laser
Print Speed	Up to 12 ppm color / 15 ppm black
Print Resolution	1200 x 2400 dpi
Monthly Duty Cycle	Up to 30, 000 pages
Standard Paper Capacity	150 sheets
Memory	128 MB
Paper Output Capacity	100 sheets
Duplex Printing	Manual
Maximum Paper Capacity	150 sheets
Supported Operating Systems	Windows, Mac OS, Linux
Connectivity	USB 2.0
Weight	24.3 lbs
